LX Electric Single Beam Suspended Crane
1. Main conditions
Light and small crane with track and usually used together with CD1 MD1 electric hoist as a complete set. Generally the lifting capacity is 0.5-10t, the span is 3-16m, with the travelling speed of 20m/min or 30m/min. We can also supply the non-standard equipment as your specially requirement.
2. Application area
The working grade of this crane is A3~A5. The working environment is -25 -40°C, and the relative humidity is no higher than 85%. It is suitable to work in such conditions without combustible, explosive, corrosive media, and be careful of melted and extremely poisonous objects.
Such kinds of cranes are widely used at places like industrial and ore enterprise, warehouses, material yard and others because of it compact structure, good rigidity, flexible installation and operation, lower noise, no pollution, safe and reliable, and etc.
The working power source of this crane is 380V, 50HZ, 3PH, AC, or according to your demands.
3. The basic structure
LX type crane is mainly composed of main girder, end carriages, electric crab, electric equipment and the travelling mechanism.
The main girder can be in form of I shape, box type, or combine structure according to different lifting capacity and span.
Lifting capacity |
0.5t |
1t |
2t |
3t |
5t |
10t |
|||
span |
3~16m |
||||||||
Crane traveling mechanism |
Traveling speed |
20/30 m/min |
|||||||
motor |
0.5~3t |
ZDY12-4/0.4KW*2 n=1380r/min |
|||||||
5~10t |
ZDY21-4/0.8KW*2 n=1380r/min |
||||||||
Lifting mechanism |
Electric hoist |
model |
CD1/MD1 |
||||||
Lifting speed |
0.5t~5t |
8,0.8/8 m/min |
|||||||
10t |
7,0.7/7m/min |
||||||||
Lifting height |
6;9;12;18;24;30m |
||||||||
Traveling mechanism |
Traveling speed |
20/30m/min |
|||||||
motor |
Taper type rotor motor |
||||||||
Working system |
Intermediate FC=25% |
||||||||
power |
3-phase AC380v 50hz |
||||||||
Diameter of the wheel |
0.5~3t |
134mm |
|||||||
5~10t |
154mm |
||||||||
Applicable track I-steel |
0.5~2t |
120a~145c |
|||||||
3~5t |
132a~145c |
||||||||
10t |
140b~163c |
||||||||
Safety feature:
Weight overload protection device,
Crane traveling limit switch,
Voltage lower protection function,
Emergency stop system,
current overload protection system,
Top quality long time bearing polyurethane materials buffer...
Quality Control:
All cranes must be pre-assembled and tested before leaving factory and offer
the certification of test.
