Specifications
Bird SA-6000EX Site Master Analyzer for The communication base stationBird SA-6000EX Site Master Analyzer, brand new with full
better than Anritsu 331L/331D Bird SA-6000EX siter master in stock
Anita
Shenzhen Hontek Co., Ltd.
Web:
Skype ID:anita.hsv
Phone:0086-13798580405
Tel:0086-0755-36934393
Features and Benefits:
• Frequency Range: 25 MHz to 6 GHz
• Rejects "On-Frequency" interference up to +13dBm
• Maximum Input: +22 dBm
• Trace overlays to track performance over time
• Saves 15 Calibrated Setups
• Stores 500 traces at 238 pts of resolution
• Alphanumeric labeling of saved traces
• Color display is viewable in direct sunlight
• Includes a Digital Power Meter option
Precision calibration components are recommended and required for accurate measurement
Standard Accessories (Included):
• AC/DC Power Cords, Manual • PC Tools Software, Battery, Soft Case
SA-6000EX (25 to 6000MHz) Site Analyzer from Bird Technologies is designed to test RF Power Measurements, VSWR Testing and Distance to Fault (DTF) estimation for the RF cable fault identification.
The Site Analyzer combines ease-of-use with powerful measurement and data analysis to help perform predictive maintenance. PC software allows download to PC to analyze data for long-term assessment of system trends, problems, and performance. No options are needed for power measurement, just purchase an In-Line 5010, 5012 or Terminating 5011 power sensor. A presentation highlighting site analyzers testing philosophy can be referred to for further details. In addition, there are a few white papers as well, which would assist you in enhancing your knowledge about cable, antenna tests performed by the industry.
| Altitude: | Up to 15,000 feet (4572 m) |
| Data Transfer: | 9 pin-RS-232 (DB9), compatible with serial port |
| Dimensions: | 10.5" x 8.4" x 3.3" (265 mm x 212 mm x 83 mm) |
| External AC: | 90 to 264 Vac @ 45-66 Hz; AC/DC adapter required |
| External DC: | 9-16 VDC fused, <3 A |
| Frequency Range: | 25-6000 MHz |
| Frequency Resolution: | 25 kHz; 25-800 Mhz, 50 kHz; 800-2500 MHz, 100 kHz; 2500-6000 MHz |
| Humidity: | 95% ± 5% max. (non-condensing) |
| Immunity to Interfering Signals: | Rejects on-frequency signals up to +13 dBm |
| Impedance: | 50 Ohms |
| Internal Time: | Rechargable Lithium-Ion batteries, 3 hour minimum operating time. Auto shut-off conserves battery life. |
| Maximum Input Signal: | +22 dBm |
| Operating Temp.: | -10°C to 50°C (14°F to 122°F) |
| Power Measurement: | Yes |
| Return Loss: | 0 to -60 dB |
| Setup Storage Capacity: | 15 Set-Ups/(500) 238 point traces |
| Speed: | 1 multi-frequency scan (238 points)/2 seconds; 1 multi-frequency scan (475 points)/3.5 seconds; 1 multi-frequency scan (949 points)/6 seconds |
| Storage Temperature: | -40°C to 80°C (-40°F to 176°F) |
| Test Port: | N-type female connector |
| Trace Resolution: | 238 (default), 475, or 949 per trace |
| Upgradeable: | No |
| Weight: | 5.5 lbs. (2.5 kg) |
