EXFO FPM-302/FPM-302X Power Meter PRICE
EXFO Optical Power Meter FPM-300 series (FPM-302/FPM-302X)
Include FPM-302 and FPM-302X
10 dBm to -50 dBm
26 dBm to -35 dB
Model |
FPM-302 |
FPM-302X |
Power meter port |
Ge |
GeX |
Power range(dBm) |
10 to −60 |
26 to −50 |
Range displayed (dBm) |
Down to −65 |
Down to −50 |
Number of calibrated wavelengths |
10 |
10 |
Power uncertainty |
± 5 % ± 1 nW |
± 5 % ± 10 nW |
Resolution (dB) |
0.01 |
0.01 |
Automatic offset nulling |
Yes |
Yes |
Warmup time(s) |
0 |
0 |
Display units |
dB/dBm/W |
dB/dBm/W |
Automatic wavelength recognition |
Yes |
Yes |
Screen refresh rate (Hz) |
3 |
3 |
Tone detection (Hz) |
270, 1 k, 2 k |
270, 1 k, 2 k |
Battery life (hours) (typical) |
> 300 |
> 300 |
|
Warranty and recommended
calibration interval (years)
|
3 |
3 |
General Specifications | ||
Size (H x W x D) |
18.5 cm x 10.0 cm x 5.5 cm |
71/4 in x 4 in x 21/8 in |
Weight |
0.4 kg |
0.9 lb |
Temperature operating |
-10 °C to 50 °C |
(14 °F to 122 °F ) |
storage |
-40 °C to 70 °C |
(-40 °F to 158 °F) |
Relative humidity |
0 % to 95 % non-condensing |
|
NOTES
a. Guaranteed unless otherwise specified.
b. All specifications valid at 1550 nm and 23 °C ± 1 °C, with an FC connector.
c. In CW mode; sensitivity defined as 6 x rms noise level.
d. Wavelengths: 830 nm, 850 nm, 980 nm, 1300 nm, 1310 nm, 1450 nm, 1490 nm, 1550 nm, 1590 nm and 1625 nm.
e. Traceable to NIST; FPM-302X: up to 20 dBm.
f. From 10 dBm to –50 dBm.
g. From 26 dBm to –35 dBm.
h. Power of > –40 dBm for FPM-302, and of > –25 dBm for FPM-302X.
i. For ± 0.05 dB and temperatures of > 18 °C.
j. At 850 nm, 1300 nm, 1310 nm, 1490 nm, 1550 nm and 1625 nm; power of > –50 dBm for FPM-302, and of > –40 dBm (typical) for FPM-302X.
****************************************
