TK-1-860 Kit - EXFO Ethernet tester FTB-1/FTB-860/FTB-1-860G NetBlazer

Name: TK-1-860 Kit - EXFO Ethernet tester FTB-1/FTB-860/FTB-1-860G NetBlazer
Brand: EXFO
Price: Negotiable

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 50 Set / Sets per Month
Port Hongkong
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Canada

Brand Name:

EXFO

Model Number:

FTB-860

Packaging Details

standard packing,Size (H x W x D) 190 mm x 252 mm x 66 mm
Weight(with battery) 1.5 kg (3.3 lb)

Product Description

TK-1-860 Kit - EXFO Ethernet tester FTB-1/FTB-860/FTB-1-860G NetBlazer

Contact information

Mobile: 0086-13823128817

Tel:+86-755-36934393

Fax: 0086-755-33503470

Website: www..hk

Skype: kitty.hsv

FTB-1 platform

Display	Touchscreen, color, 640 x 480 TFT 163 mm (6.4 in)
Interfaces	USB A main USB B remote RJ-45 LAN 10/100 Mb/s Compact Flash Fiber inspection probe connector port (video)
Storage	Internal 80 MB (Flash) USB sticks 1 GB and 2 GB (optional) Compact Flash cards (optional)
Batteries	Rechargeable Li-Ion 8 h of operation as per Bellcore TR-NWT-001138
Power Supply	AC/DC adapter, input 100-240 VAC, 50-60 Hz, 2 A max, output: 24 VDC, 90 W

GENERAL SPECIFICATIONS
Temperature
Operating	-5 °C to 50°C
Storage	-40 °C to 70 °C
Relative humidity	0 % to 95 % non-condensing
Size (H x W x D)	322 mm x 197 mm x 109 mm (12 11/16 in x 7 3/4 in x 4 5/16 in)
Weight	2.5 kg (5.4 lb)
Vibration	< 1.5 g at 10 Hz to 500 Hz (on three main axes)
Mechanical shock	< 760 mm on six sides and eight main edges (according to GR-196-CORE)

Ethernet Test Module FTB-860 NetBlazer Gigabit

FTB-860

10/100/1000 Electrical & 1000 Optical Ethernet Test Module and Fibre Channel 1,2,4X

Ethernet testing including:
- Dual port 10/100/1000 Base-T Electrical Interface
- Dual port 1000 Base-X optical interface
- Supports EtherSAM, RFC-2544,Traffic Generation, BERT,
Smart Loopback, 3rd party loopback, Ping, Trace Route
and Intelligent auto discovery

Upgrades note(s):
1- Upgradeable to 100M Optical interface
Order using the following part. no. 100optical

2- Upgradeable to Fibre Channel 1,2 or 4X

Note:
Rates enabled by default in this model are listed explicitly in the description. Additional rates can be enabled as well with additional options.

Ethernet Test Module FTB-860G NetBlazer Gigabit and 10 GigE

FTB-860G-1

10/100/1000 Electrical & 1000 Optical Ethernet Test Module

Ethernet testing including:
- Dual port 10/100/1000 Base-T Electrical Interface
- Dual port 1000 Base-X optical interface
- Supports EtherSAM, RFC-2544,Traffic Generation, BERT,
Smart Loopback, 3rd party loopback, Ping, Trace Route
and Intelligent auto discovery

Upgrades note(s):
1- Upgradeable to 10 GigE optical LAN/WAN testing
     Order using the following part. no. 10 GigE

2- Upgradeable to 100M Optical interface
     Order using the following part. no. 100optical

3- Upgradeable to Fibre Channel 1,2,4,8,10X

4- Other software options can also be ordered at a later time
       for upgrade.

Note:
Rates enabled by default in this model are listed explicitly in the description. Additional rates can be enabled as well with additional options.
