Newest EXFO OTDR EXFO FTB-1v2/FTB-1 PRO FTB-700C PON FTTx/MDU FTTH OTDR

Name: Newest EXFO OTDR EXFO FTB-1v2/FTB-1 PRO FTB-700C PON FTTx/MDU FTTH OTDR
Brand: EXFO
Price: USD $4,300 - 6,000 / Set

FOB Price

USD $4,300 - $6,000 / Set

1 Set(Min.Order)

Supply Ability 50 Set / Sets per Month
Port HK
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Canada

Brand Name:

EXFO

Model Number:

FTB-1v2/FTB-1 PRO

Packaging Details

standard packing,Size (H x W x D) 190 mm x 252 mm x 66 mm
Weight(with battery) 1.5 kg (3.3 lb)

Product Description

Newest EXFO OTDR EXFO FTB-1v2/FTB-1 PRO FTB-700C PON FTTx/MDU FTTH OTDR

Contact information

Mobile: 0086-13823128817

Tel:+86-755-36934393

Fax: 0086-755-33503470

Website: www..hk

Skype: kitty.hsv

Specification:

Description:

The FTB-1 version 2, available in a standard (FTB-1 V2) or Pro (FTB-1 Pro) model, is a
portable system designed for fast and powerful optical, Ethernet, time-division multiplexing
(TDM) and multiservice applications.

Includes : - Instruction Manual (Soft Copy)
(Mainframe) - Quick Reference Guide (Hard copy)
- GP-2253: Li-Ion smart battery (qty:1)
- GP-2233: 90W, AC Adapter with power cord
- GP-2232: Hand strap
- GP-2151: Hook strap
- GP-2235: Stylus (qty:1)

"Single-slot capacity Modular mainframe
Windows 8.1 Pro OS, QUAD Core CPU
- Multi-touch widescreen, color, 1280 x 800 TFT, 203 mm (8 in)
- RAM: 4 GB Internal memory
- Interfaces:
> RJ-45 LAN 10/100/1000 Mbit/s
> USB 2.0 ports (qty:2)
> USB 3.0 port
> 3.5 mm audio jack (speaker/mic)

Models	Description
FTB-720C-SM1-XX	SM OTDR Module 1310/1550 nm, 36/34 dB (9/125 µm)
FTB-720C-SM2-XX	SM OTDR Module Port 1: 1310/1550 nm, 36/35 dB (9/125 µm) Port 2: Filtered 1625 nm, 35 dB (9/125 µm) for live fiber testing
FTB-720C-Q1-XX	MM OTDR Module Port 1: 850/1300 nm, 27/29 dB (50/125 & 62.5/125 µm) Port 2: SM Hardware ready and field upgradable to 1310/1550 nm
FTB-720C-Q1-QUAD-XX	QUAD OTDR Module Port 1: 850/1300 nm, 27/29 dB (50/125 & 62.5/125 µm) Port 2: 1310/1550 nm 36/35 dB (9/125 µm)
FTB-730C-SM1-XX	SM OTDR Module 1310/1550 nm, 39/38 dB (9/125 µm)
FTB-730C-SM2-XX	SM OTDR Module Port 1: 1310/1550 nm, 39/38 dB (9/125 µm) Port 2: Filtered 1625 nm, 39 dB (9/125 µm) for live fiber testing
FTB-730C-SM3-XX	SM OTDR Module 1310/1550/1625 nm, 39/38/39 dB (9/125 µm)
FTB-730C-SM8-XX	SM OTDR Module Port 1: 1310/1550 nm, 39/38 dB (9/125 µm) Port 2: Filtered 1650 nm, 39 dB (9/125 µm) for live fiber testing
FTB-730C-SM6-XX	SM OTDR Module Filtered 1625 nm, 39 dB (9/125 µm) for live fiber testing
FTB-730C-SM7-XX	SM OTDR Module Filtered 1650 nm, 39 dB (9/125 µm) for live fiber testing
FTB-735C-SM1-XX	SM OTDR Module 1310/1550 nm, 42/41 dB (9/125 µm)
FTB-735C-SM2-XX	SM OTDR Module Port 1: 1310/1550 nm, 42/41 dB (9/125 µm) Port 2: Filtered 1625 nm, 41 dB (9/125 µm) for live fiber testing
FTB-735C-SM3-XX	SM OTDR Module 1310/1550/1625 nm, 42/41/41 dB (9/125 µm)
FTB-735C-SM4-XX	SM OTDR Module 1310/1490/1550 nm, 42/41/41 dB (9/125 µm)
FTB-750C-SM1	SM OTDR Module 1310/1550 nm, 46/45 dB (9/125 µm)
FTB-750C-SM3	SM OTDR Module 1310/1550/1625 nm, 45/45/45 dB (9/125 µm)
