Specifications
diesel generator set1top qualty,factory price
2,380v,cummins generator set
3,single phase or three phase
diesel generator set
1top qualty,factory price
2,cummins generator set,380v
3,single phase or three phase
disel generator specification
| Model | WY-CM50(S) | ||
| Cont.AC outpu(KW) | 40 | 45 | |
| Max.output(KW) | 45 | 50 | |
| Voltage(V) | 380V,400V,440V | ||
| Frequency(Hz) | 50 | 60 | |
| Power factor | 0.8 | ||
| GENERATOR | Model | WY224D | |
| Cont.AC output(KW) | 40 | 45 | |
| Max.output(KW) | 45 | 50 | |
| Excitation SyStem | Brushless excitation | ||
| InSulation Class | H | ||
| ConStruction Type | SAE engine adaptor (single-bearing or double-bearing) | ||
| ENGINE | Model | 4BTA3.9-G2 | |
| Number of cylinders | 4L | ||
| Bore×stroke(mm) | 102×120 | ||
| Compression Ratio | |||
| Displacement(L) | 3.9 | ||
| Specific fuel consumption (g/kW.h) |
≤209 | ||
| Rated speed(r/min) | 1500 | 1800 | |
| Cont.output(kW) | 50 | 55 | |
| Max.outout(kW) | 55 | 60 | |
| Starting system | Electric | ||
| Cooling method | Closed circle water-cooled | ||
| Starting battery | 12V/120AH | ||
| Gensetfor protection | The protection of low accumulator,overspeed,high water temperature,low press-gas | ||
| ing time(h) | 12 | ||
| Overall dimensions(mm) | 2250*950*1150 | ||
| Package dimensions(mm) | 2350*1000*1220 | ||
| Net weight(kg) | 1120 | ||
| Dry weight(kg) | 1170 | ||
3) Control System:
Main Function:
3.1: Control Function: Start and Stop the generator set
3.2: Display function: Collect the parameters of frequency, voltage etc and display them on LCD panel, display the engine parameters of engine speed, oil pressure, water temperature operating time, battery voltage and so on.
3.3: Protecting and Alarming Function: Display failure of low oil pressure, high water temperature, dead start, stop failure, over pressure, lose pressure, charging failure etc, protecting and alarming function.
3.4: Equipped with emergency stop button. When there is emergent situation, the generator set can be stopped manually to ensure the security.
3. Global Warranty:
One Year or 1000 running hours whichever is earlier against any manufacturing defects.
4. Packing:
Wooden case packing or according to customer’s requirement.
5. Delivery Time:
Within 20 working days after receiving the advanced payment.
6. Payment Terms:
T/T,L/C in advance.
