Cunmins 3kw Diesel Generator
US$ 1 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
wonyong
Model Number:
WY-CM75
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
30kw Diesel Genset GeneratorUS$ 1 - 10,000MOQ: 1 Set -
Diesel Generator 25kwUS$ 1 - 10,000MOQ: 1 Set
-
45kva Diesel Generator SetUS$ 1 - 10,000MOQ: 1 Set
-
95kva CE & ISO Approved Cummins Disel Generator 20kw-1000kwUS$ 1 - 50,000MOQ: 1 Set
-
Cummins Diesel Generator Set With Fuel TankUS$ 1 - 50,000MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
wonyong
Model Number
WY-CM75
Output Type
AC Three Phase
Speed
15001800RPM
Frequency
50/60HZ
Rated Power
75KW
Rated Voltage
380V
Rated Current
other
Specifications
cunmins 3kw diesel generator1factory price,water-cooled,4 cylinders
2,3phase ,50/60hz 380v,open skid
cunmins 3kw diesel generator
1factory price,water-cooled,4 cylinders
2, 3phse ,50/60hz 380v,open ski
3.1year warranty &best after service
4.steady power in working time
cunmins 3kw diesel generator specification
| Model | WY-CM57(S) | WY-CM75(S) | |||
| Cont.AC outpu(KW) | 45 | 50 | 60 | 66 | |
| Max.output(KW) | 50 | 55 | 66 | 73 | |
| Voltage(V) | 220/380 | 220/380 | |||
| Frequency(Hz) | 50 | 60 | 50 | 60 | |
| Power factor | 0.8 | 0.8 | |||
| GENERATOR | Model | WY224E | WY224F | ||
| Cont.AC output(KW) | 50 | 55 | 60 | 66 | |
| Max.output(KW) | 55 | 60 | 66 | 73 | |
| Excitation SyStem | Brushless excitation | Brushless excitation | |||
| InSulation Class | H | H | |||
| ConStruction Type | SAE engine adaptor (single-bearing or double-bearing) | SAE engine adaptor (single-bearing or double-bearing) | |||
| ENGINE | Model | 4BTA3.9-G2 | 6BT5.9-G2 | ||
| Number of cylinders | 4L | 6L | |||
| Bore×stroke(mm) | 102×120 | 102×120 | |||
| Compression Ratio | |||||
| Displacement(L) | 3.9 | 5.88 | |||
| Specific fuel consumption (g/kW.h) |
≤209 | ≤210 | |||
| Rated speed(r/min) | 1500 | 1800 | 1500 | 1800 | |
| Cont.output(kW) | 50.0 | 55 | 92 | 102 | |
| Max.outout(kW) | 55 | 60 | 102 | 112 | |
| Starting system | Electric | Electric | |||
| Cooling method | Closed circle water-cooled | Closed circle water-cooled | |||
| Starting battery | 12V/120AH | 12V/120AH | 2×12V/120AH | ||
| Gensetfor protection | The protection of low accumulator,overspeed,high water temperature,low press-gas | The protection of low accumulator,overspeed,high water temperature,low press-gas | |||
| ing time(h) | 12 | 12 | |||
| Overall dimensions(mm) | 2250*950*1150 | 2900*1050*1500 | |||
| Package dimensions(mm) | 2350*1000*1220 | 3000*1120*1600 | |||
| Net weight(kg) | 1150 | 2050 | |||
| Dry weight(kg) | 1200 | 2150 | |||
cunmins 3kw diesel generator packing
cunmins 3kw diesel generator warranty
12 months or 1000 running hours from shipment date. If the quality problem arise during the warranty period,and verified the problem is caused by our genset-body instead of external or natural reasons. (Refer to all kinds of natural disaster, shipping, loading, unloading, wrong-operation, etc), we will supply the relevant spare parts free of charge for maintenance; after the warranty period, we can supply the required spare parts for you under cost prices
