Specifications
1.power 40-400kw,3P,4W, shangchai engine2.delivery in 20days
3.CE,ISO9001,3C
4.1year or 1000hours warranty
Specifications
diesel generator
1.power 40-400kw,3P,4W, shangchai engine
2.delivery in 20days
3.CE,ISO9001,3C
4.1year or 1000hours warranty
Diesel Generator
1. Genset specification:
1).3 Phase 4 Wire
2).Voltage: 400V / 230V, 380V / 220V, 110V / 220V
3). Frequency: 50/60HZ
4). Rated speed: 1,500 and 1,800rpm
5). Rated output: 50-650kw
6). Power factor: 0.8 lagging
2.Engine specification:
1) Starting type: electric start
2) Cooling model: forced water cooled
3)Engine Direct combustion chamber, supercharging internal cooling, integrated high intensity cylinder Alternator
3. Alternator: Stamford, Leroy Somer, Marathon series, and our Xinhengxin brand brushless alternators TFWS(copy Stamford) and XHX2(copy Leroy somer) series, STC brush type
1).Excitation mode: brush or brushless
2) Voltage adjustment: ±1%
3) Protection class: IP21/23
4) Insulation class: Class H
4.Control panel: Emergency stop button, voltmeter, ammeter, frequency meter, Four protection, and ATS & AMF panel on required.
Model |
Rated Power (KW/KVA) |
Rated Curr. (A) |
Fuel Consumption (f/KW.h) |
Engine Type |
Dimension (mm) L×W×H |
GF-40 |
40/50 |
72 |
13 |
4135D-1 |
2200×800×1400 |
GF-50 |
50/62.5 |
90 |
231.2 |
4135D-1 |
2200×800×1400 |
GF-64 |
64/80 |
115 |
231.2 |
4135AD |
2250×800×1400 |
GF-80 |
80/100 |
135 |
220 |
4135AZD-1 |
2250×800×1400 |
GF-100 |
100/125 |
180 |
220 |
4135AZD-2 |
2500×800×1400 |
GF-120 |
120/150 |
216 |
225.8 |
6135JZD |
2800×950×1550 |
GF-140 |
140/175 |
270 |
225.8 |
6135AZD-1 |
2800×950×1550 |
GF-150 |
150/188 |
270 |
225.8 |
6135AZD-1 |
2800×950×1550 |
GF-160 |
160/200 |
324 |
225 |
G128ZLD |
2800×970×1670 |
GF-180 |
180/225 |
325 |
225 |
G128ZLD2 |
2900×970×1750 |
GF-200 |
200/250 |
361 |
225 |
G128ZLD2 |
2900×970×1750 |
GF-220 |
220/275 |
397 |
225 |
G128ZLD1 |
2900×970×1750 |
GF-250 |
250/321.5 |
451 |
232.6 |
12V135JZD |
3400×1400×1960 |
GF-280 |
270/337.5 |
505 |
220 |
12V135AZD |
3600×1400×1960 |
GF-300 |
300/375 |
505 |
220 |
12V135AZD |
3600×1400×1960 |
GF-320 |
320/400 |
577 |
210 |
12V135AZLD |
3600×1400×1960 |
GF-350 |
350/438 |
649 |
210 |
12V135BZLD |
3800×1500×2015 |
GF-400 |
400/500 |
649 |
210 |
12V136BZLD |
3800×1500×2016 |
Warranty policy:
Guarantee for one year or 1000 hours of the total running time. During the guarantee period, we will supply freely the easy damaged parts for the possible problems except for the incorrect operation. After expiration, we supply cost spare parts for gen set maintenance
