Vertical froth pump

EVF-2Q Good performance vertical froth slurry pump

Excellence Pump Industry Co., Ltd is a professional slurry pump manufacturer in China. With the accumulation and development of years, we have formed a complete system of slurry pump design, selection, application and maintenance. Under the confidence of our clients home and abroad, we are becoming one of the most important slurry pump suppliers in China, and we have offered the professional pump solutions and service over 60 countries in the world.

Test system Operation Panel                                            Machining Worker

Introduction of Froth Pump---EVF Series

Series EVF froth pumps are the latest generation of froth pump based on the advanced technology at home and abroad. It could eliminate the froth in the slurry in running and work normally even if the feeding slurry is not enough.EVF pump is the ideal products to deliver the frothy slurry, especially in the flotation technique process.

Features of Froth Pumps

1, Series EVF pumps use bearing assembly of VA, VB and PNL.On the bearing house, there is the motor base or motor support, which helps adopt belt drive and direct drive. It is very convenient to change the pulleys to adjust the speed and meet the changes of the work conditions.

2 , The box is made of steel, stainless steel or rubber lined steel. It has the feeding suction and overflow box in the tangent line. The overflow box could deliver the surplus slurry back to the pool. The feeding suction in the tangent line could transport the slurry fast and eliminate part of the froth.

3 Series EVF pumps are of double-casing. The materials of the wet parts could be metal alloy, rubber or other non-metal material according to the slurry properties.

Application:

It is used widely in the metallurgy, minerals, coal washery, chemical and other industrial departments, suitable for handing the abrasive and corrosive slurry with the froth.

                                                                     Gold Plant of Zijin Mining Group

  Test System

Data Checking

Test System Operation Panel
