Good performance Flue Gas Desulfurization pump
Excellence Pump Industry Co., Ltd is a professional slurry pump manufacturer in China. With the accumulation and development of years, we have formed a complete system of slurry pump design, selection, application and maintenance. Under the confidence of our clients home and abroad, we are becoming one of the most important slurry pump suppliers in China, and we have offered the professional pump solutions and service over 60 countries in the world.
Brazil clients satisfied with EXCELLENCE products Test System
Detailed Product Description
1. High corrosion resistance desulphurization pumps
2. Centrifugal FGD project pump
Type ETL Series Desulphurization Pumps
Caliber (mm): 600-900;
Capacity (m3/h): 5300-14000;
Head (m): 23-40
FGD Project
Advanced Flow Simulation Analysis
Cartridge Mechanical Seal
A49 duplex Stainless White Iron Material
Product Description
The pump restricting parts adopt the advanced flow simulation technology to guarantee the reliable pump design and the high operating efficiency.The anti-corrosion & anti-wear metal and rubber materials which are specifically developed for FGD pumps have been proved by the practice that they can ensure the long-life pump operation. Through adjusting the bearing components to change the impeller position in the pump chamber all-time high-efficient operation of the pump can be achieved. The pump is characterized by the back knock-down structure which is simple and advanced.
It is easy to maintain and repair and it is on need dismantling inlet and outlet water pipes. The containerized mechanical seal specially used for the desulphurization process is adopted and its operation is reliable
Features
The wet parts adopt the advanced flow simulation analysis in the design process to guarantee the reliable performance, high efficiency of the pumps. The customer can make the pump always running in an efficient operation state by adjusting the bearing components in the pump impeller to suit the cavity position of the pump.
The pumps are designed with rear-assemblage structure system. They are featured by easy structure and it is easy to repair without dismantling the inlet and outlet pipe of the pump. End bearing adopts imported tapered roller bearings and driving end uses two cylindrical roller bearings with thin oil lubrication. It can promote the bearings’ working condition to prolong the service life of bearings.
Mechanical seal is designed according to the structure characteristic of desulphurization pump, slurry characteristic and the application characteristic. It is cartridge mechanical seal. It has good performance, long service life.
The FGD (Flue Gas Desulfurization) equipment of the pump is made of a new type of material A49 duplex stainless white iron which is specially developed by our company itself. The new material has significant corrosion-resistant and wear-resisting performance. The pump, pump cover and splice plates are pressure parts and made of ductile cast iron. The impeller and suction cover is made of the A49 dual-phase stainless white iron. The material of cover plate liner, frame plate liner, and rear liner is natural rubber with natural good abrasion performance, light weight, relatively low cost.
Applications
They are mainly used to handle slurry with smoke in absorption
