PP/PE string cutting granulating line, specially designed for PP/PE crushed flakes, or PP/PE scraps,bags,films. recycling granulating,
we can produce machines for capacity from 100kg/h to 500kg/h,
different capacity ,different material will be equipped with different model machines.
Here I offer one of our China origin 300kg/h PP PE woven bags pelletizing line for your reference.
Major parts of China origin 300kg/h PP PE woven bags pelletizing line:
NO. |
Major parts |
Detail information |
I |
300L Agglomerate machine |
1,Driving motor:55KW, 2,Effective volume 225L, 3,Stainless steel barrel, 4,Rotor blades 6pcs,fixed blades 4pcs, 5,SKD-11 alloy steel material blades, 6,Air cylinder discharge material 7,capacity:150-200kg/h |
II |
Screw Conveyer |
1,Feeding motor: 1.1KW,Discharge motor:0.75KW, 2,Diameter of feeding pipe:102mm 3,Feeding capacity:500kg/h,hopper volume:150kg |
III |
Force feeder hopper |
1,Feeding motor:1.1KW, 2,Hopper diameter:500mm,height:600mm 3,automatic feeding, 4,Parts contacted with mateial are stainless steel |
IV |
SJ-120/32 Single Screw Extruder |
1,Motor:55KW, barrel heating:48KW(6KW*8sections), barrel cooling:(0.37KW*8sections) blower cooling, vacuum pump venting:1.5KW 2,Gear box:high torque,low noise,hard gear surface, Fused melt pressure,temperature measuring. |
V |
Hydraulic screen changer |
1,Two filter screen,one hydraulic station, 2,Oil pump:1.5KW 3,Nonstop machine when change screen |
VI |
Water tank |
1,Length:4000mm,width:400mm,height:400mm, 2,Strand guiding rollers:6pcs,made of nylon, 3,Cooling method:recycling water cooling, 4,Tank moving:4 wheels, 5,Strand drying method:air drying. |
VII |
Pelletizer |
1,Motor power:4KW, 2,Diameter of final products:3*3mm 3,Pelletizing rotor blades 1pc,fixed blades 1pc, 4,Blade material:alloy steel. |
VIII |
Stoage hopper |
1,Volume:500L 2,Blower power: 2.2KW 3,Parts contacted with mateial are stainless steel |
X |
Electric control panel |
1,There is a pressure transducer to warn over pressured, 2,Every equipment has a pilot lamp to show the working state. |
Advantage:
- world famous brands major parts:
| Motor | SIEMENS |
Inverters |
ABB/ FUJI / LG / OMRON |
| Contactors | SIEMENS / Schneider |
| Temperature controllers | OMRON/ RKC |
| PLC system | SIEMENS/ DELTA |
- Skilled workers for machines producing
- Experience engineers all with passports ready for customers services
- Good Prices get from square quantity major parts purchase with lower cost
- Full line running test for customer checking before delivery
- Packaging: poly-wooden cases for China origin 300kg/h PP PE woven bags pelletizing line
, no need fumigate; bubble films packaging
- We suggest the customer to purchase poly-wooden case packaging; if no, we will fixed the machines on containers walls with steel wires
- pre-sales services: we will take customers to visit our factory and check the machines quality from airport/bus station/train stations
- we will re-designed the machines according to customer's different raw material formulations: driving motors power, electric power model, wall thickness of barrel, control method
- after sales services: we will offer electric diagram, installation diagram, usage manual
- we will offer the customers online introduction to solve the machines problems/send engineers for customers machines installation, running test, workers training, machines repairmen services.
- we will offer customers spare parts at cost prices all life long of the machines
- BEIERMAN MACHINERY was established by three skilled technician/engineer/sales for plastic extruding line, plastic recycling lines producing, sale and services.
- We have 3000 square meters working house for machines making, there are 40 workers for machines producing and a 5 engineers service team for the machines running test, installation, workers training and machines repairmen.
- we have already get CE and ISO9001 certificated for our machines and factory, which ensured the high quality level of all machines we are producing
- we will attend several home and abroad plastic machines industry fairs to show the customers our quality, machines and services.
- there will be 1-2 new produced machines will be showed to the customers every year.
- we already established cooperation with the customers from Middle East, Southeast Asia and south America countries.
