Specifications
Ultrasonic ribbon automatic cutter1.PLC control
puter counting
3.high precision and speed
4.simple length adjustmen
Ultrasonic ribbon automatic cutter
(NK-CJQ1526A)
Features and functions of Ultrasonic ribbon automatic cutter:
1.Smooth and tidy cutting edge, free of burr or fuzzy edge, optimum cutting
2.PLC control automatic feeding, computer counting, high precision, high speed, simple length adjustment, high efficiency and concurrent cutting.
3.Used mostly for strip cotton tapes, nylon tapes, strip ribbon, shaped into circle, swallowtail, rhombus, etc
4.If the width of the tape that you want to cut is less than one inch,you can cut two pieces in one time.
Technical Data of Ultrasonic ribbon automatic cutter:
Supply voltage |
220V(Single) |
Power |
1500W |
Frequency |
20KHz |
Air press |
4-6kg/cm2 |
Mould Size |
80x25mm |
Cutting Width |
75mm |
Cutting Length |
13mm-3.2m |
Cutting Thickness |
1mm-4.5mm |
Speed |
30-35m/min |
Precision |
±1mm |
Dimension |
1200x700x1300mm |
Weight |
75KG |
Mould of Ultrasonic ribbon automatic cutter:
Sample of Ultrasonic ribbon automatic cutter:
Factory Information:
Dongguan City South Nekon Machinery Co., LTD was founded in 1997, located in the beautiful Shipai Town of Dongguan City, Guangdong Province. South Nekon is a high technical private enterprise owing independent import-export operation rights. Since the establishment, the company has been devoted to optimization and integration of developing, producing, selling, and applicating of technology of ultrasonic machinery (Ultrasonic rhinestone fixing machine,face mask making machine, ultrasonic ribbon cutting machine, ultrasonic lace sewing machine, ultrasonic plastic welding machines, high frequency fusing machine).
