Help CenterSynthetic Rubber Water Stop Strap
Related Products
Specifications
1.Synthetic Rubber Water Stop Strap2.Used for block dam subway,culverts
3.tunnels underground building
4.high elastic
Synthetic Rubber Water Stop Strap
Application of Synthetic Rubber Water Stop Strap
- Block dam, reservoir, the subway, culverts, tunnels underground building
- Roofing and other building material
- Mainly structures of water-proof deformed joints
- Water conservancy, construction, civil air defense, , highway, railway, Bridges
No. |
Inspection Item |
Index |
||||
B |
S |
J |
||||
1 |
Hardness (Shore A, degree) |
60±5 |
60±5 |
60±5 |
||
2 |
Tensile Strength (MPa) ≥ |
15 |
12 |
10 |
||
3 |
Elongation at break (%) ≥ |
380 |
380 |
300 |
||
4 |
Compression Permanent Deformation(%) |
70°Cx24h ≤ |
20 |
20 |
20 |
|
5 |
23°Cx168h ≤ |
30 |
25 |
25 |
||
6 |
Tearing Strength(KN/m) ≥ |
-45 |
-40 |
-40 |
||
7 |
Brittleness Temperature(°C) ≤ |
35 |
35 |
35 |
||
Air Aging |
70°C x168h |
Hardness Change(Shore A, Degree) ≤ |
+8 |
+8 |
- |
|
Tensile Strength (MPa) ≥ |
12 |
10 |
||||
Tensile Failure Elongation(%) ≥ |
300 |
300 |
||||
100°C x168h |
Hardness Change(Shore A, Degree) ≤ |
- |
- |
+8 |
||
Tensile Strength (MPa) ≥ |
9 |
|||||
Tensile Failure Elongation(%) ≥ |
250 |
|||||
8 |
Ozone Aging 50pphm:20%,48h |
2 |
2 |
2 |
||
9 |
Bonding between Rubber and Metal |
Section in Elastic Body
|
||||
Technical specifications and performance:
1) Elastic rubber sheet is a new type of rubber material by mixing EPDM, filler, plasticizer and other addition agent first, then get vulcanized.
2) It is used on ballastless track, it can transfer horizontal and longitudinal load from the upper track effectively.
3) It can buffer horizontal and longitudinal force acting on grooves and convex plates.
4) It can also reduce the restraint stress caused by temperature and contraction.
