grilled slag machine
Product name: High quality grilled slag machine made in china
Item |
Unit |
Technical Parameter |
|||
Model No. |
|
ZWY-100/45L |
ZWY-80/45L |
ZWY-60/30L |
|
Machine weight |
Kg |
12200 |
11860 |
6800 |
|
Loading capacity |
M³/h |
100 |
80 |
60 |
|
|
|
reach boom broken boom(Optional) |
reach boom broken boom(Optional) |
|
|
Digging width |
mm |
5300 4800 |
4800 3200 |
3200 |
|
Digging distance |
mm |
1970 1820 |
1820 1530 |
1530 |
|
Digging height |
mm |
3090 2570 |
2570 2300 |
2300 |
|
Digging depth |
mm |
600 480 |
480 320 |
320 |
|
Dumping height |
mm |
1480~1760(variable) |
1470~1646(variable) |
1350(variable) |
|
Dumping distance |
mm |
1700(variable) |
1600(variable) |
1500(variable) |
|
Driving speed |
m/s |
0.25±5% |
0.25±5% |
0.25±5% |
|
Speed of scraper chain |
m/min |
40 |
40 |
34 |
|
Scraper chain transportation organization form |
|
single chain single drive |
single chain single drive |
single chain single drive |
|
Applicable roadway slope |
(°) |
≤32 |
≤32 |
≤32 |
|
Maximum working pressure |
Mpa |
≤32 |
≤32 |
≤32 |
|
Ground pressure |
Mpa |
≤0.1 |
≤0.1 |
≤0.087 |
|
Ground clearance |
mm |
≤310(can be heighten) |
≤310(can be heighten) |
≤320(can be heighten) |
|
Total Power |
Kw |
45 |
45 |
30 |
|
Operation manner |
|
Hydraulic control |
Hydraulic control |
Hydraulic control |
|
Conveyor inner width |
mm |
941(can be widen) |
941(can be widen) |
900(can be widen) |
|
Maximum material go through size(W×H) |
mm |
580×710 |
580×710 |
480×520 |
|
Working arm maximum turning angle |
(°) |
±55 |
±55 |
±55 |
|
Dimension(transport position) |
Length |
mm |
8100 |
7710 |
6030 |
width |
mm |
1690 |
1690 |
1500 |
|
height |
mm |
2100 |
1990 |
1800 |
|
Dimension(working position) |
length |
mm |
9700 |
9222 |
6500 |
width |
mm |
1690 |
1690 |
1500 |
|
height |
mm |
2310 |
2247 |
1900 |
|
adaptive tunnel dimension(W×H) |
m |
≥2.5×2.5 |
≥2.4×2.4 |
≥2×2 |
|
Quality Policy: Enterprise Spirit:
Quality First ,Customer First Honesty, Devotion, Striving, and development
Faith is root, Profession is the first WANFENG MINING MACHINERY WORTH YOUR CHOICE!
FAQ
FAQ(Frequently Asked Questions)
1, What materials will you used for your design?
A.Plain PP woven bags
(prices were relatively cheap, suitable for garbage.sand,flour,feed stuff, fertilizer and so on)
B.Printing PP woven bags (price were relatively high, suitable for rice,sugar,salt and so on)
C Nonwoven bags (prices were relatively cheap, suitable for supermarket shopping bags or used for advertising promotion gifts)
D. Laminated non woven bags (Price were relatively cheaper than cotton&canvas bag, Laminated non woven fabric have great cost advantage if the bags will have full color pattern,and order quantity is large)
E. PP woven laminated bags (prices high, a longer service life,can be washed)
F. Canvas bags (higher price relative to cotton bag, long service life even more thick cloth).
G. Polyester bags (190T,210D,420D,600D, single color fabric or colorful material)
2, Minimum Order Quantity?
A. Plain woven bag MOQ 10000pcs
B. Printing PP woven bag MOQ 20’’ft container
C. You can mix all items into one 20’’ft container
(If your order quantity is low,Pls kindly contact me and see if we have fabric at stock for this small order quantity).
3, What factors will affect the price of bags?
A. Size:The larger size, of course,larger size will cost much more, if the product size and fabric width does not match, you may create great waste, Therefore, it will lead to higher prices.
B:weight:The more weight the more material.
C:Material:Different material will be different price
D. Printing: We generally use silk screen printing,color and size will affect the final printing costs; the more color and more printing size and more complex artwork leads to the higher the price.
E. Quantity: The more the quantity, price is relatively more cheap .
4, About making sample:
we can help provide samples for you to test before order if really needed. If the customer requires a finished sample before advance deposit, It will charge according to your artwork. But in the final contract, We will refund the printing plate fee while order.
5, Packaging: about 1000pcs /Bale
6, Transportation: By sea or or by air,it's up to you
