15-80mm White Ceramic Pall Ring

15-80mm White Ceramic Pall Ring thumbnail-1
15-80mm White Ceramic Pall Ring photo-1
Negotiable MOQ: 1 Cubic Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Type:
Ceramic Rings
Application:
Industrial Ceramic
Contact Supplier Request Quote Chat Now
Wuxi Kaisheng Electricity Petrochemical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai ninbo qindao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Type Ceramic Rings
Application Industrial Ceramic
Material Alumina Ceramic
Model Number ks-c03
Brand Name Kai Sheng

Specifications

15-80mm white ceramic pall ring random packing
ISO9001-2008
Reliable manufacturer
Good price+High quality+Fast delivery

15-80mm White Ceramic Pall Ring  Packing



Ceramic Pall Ring is a new kind of packing, which is developed from the short points of the Raschig Ring,the Pall Ring has six

rectangle windows on the base of common ceramic Raschig Ring and the small window blades connecting in the center of the

ring as well as the position of adjacent windows interlapping with each other.

Ceramic Pall Ring has excellent acid resistance and heat resistance. It can resist to corrosion of various inorganic acids, organic

acids and organic solvents except hydrofluoric acid, and can be used in high or low temperature conditions, consequently the

application range is very wide. It can be used in the drying coulmns, absorbing columns, cooling towers, scrubbing towers and

actifier columns in chemical industry, metallurgy industry , coal gas industry, oxygen producing industry, etc.



Specifications

Diameter: 15mm -80mm
Certificate: ISO9001-2008



15-80mm White Ceramic Pall Ring



Technical parameter



Product:       Ceramic Pall Ring

Nominal

Dimension

DxHxT(mm)

Specific Surface Area(m2/m3)

Void

Rate

Accumulation

Number(/m3)

Accumulation

Weight(kg/m3)

Packing

Factor

Dg15

15x15x2

350

0.70

250000

690

500

Dg25

25x25x2.5

200

0.76

42000

630

300

Dg38

38x38x4

150

0.77

13400

540

153

Dg50

50x50x4

110

0.81

6000

475

200

Dg80

80x80x6

66

0.75

1800

714

100
