Home > Products > New Products > Pipe Sping Hanger and Support
Pipe Sping Hanger and Support
- 200000 Kilogram / Kilograms per Month
- shanghai qindao ninbo
- T/T D/P D/A Credit Card
Product Details
Material: | Carbon Steel | Technics: | Other, casting or forging | Type: | Other |
Place of Origin: | Jiangsu, China | Model Number: | ks-0015 | Brand Name: | ks |
Connection: | Other, pipe hanger and support | Shape: | Equal | Head Code: | Other |
Product Description
Specifications
Constant spring hanger supportVariable hanger spring support
Reliable manufacturer for 12years
Good price+High quality
Pipe Sping Hanger and Support
Load range 500-400000 n, displacement range 50-500 mm,temperature range - 20 °C ~ + 200 °C.
Type: 58H,58V,80V, ZH, TH, VS, TD, BSH
Material: carbon steel,stainless steel,alloy steel and special material for the special parts.
Size:according to the drawing or requirement
Standard:ISO, JIS,DIN,GB
58H, 58 V and 80V Constant Force Spring Hangers | ||
1. Applicable Range | ||
The 58H, 58 V and 80V constant force spring hangers (US ITT Technology) are applicable to 38mm (1 1/2") to 508mm (20") displacement, 12.7mm (1/2") interval and 12daN to 39,690daN loading capacity. | ||
2. Classification and Model | ||
Classification | Model Code | Installation Form |
Horizontal Type Constant Force Spring Hangers | 58H | A Type, B Type, C Type, E Type, G Type |
Vertical Constant Force Spring Hangers | 58V | A Type, B Type, C Type, D Type, E Type |
Support Type Constant Force Spring Hangers | 80V | F Type |
A Type-Duplex Pull Rod Connection | ||
B Type-Single Hanger Plate Connection | ||
C Type-Double Hanger Plate Connection | ||
D Type-Top Surface Connection | ||
E Type-Pedestal Connection | ||
G Type-Parallel Connection of Constant Force Spring Hangers
|
Constant Spring Hanger
Variable Spring Hanger
