2015 high power 50w white led
highest flux-100 lumensin cool white at 350mH
high efficacy,flux density and lumens per package
long operating life(lif>50000hr)
lead-free reflow solder&good reliability
| part no. | Color | Doninant wavelength/color temperature | luminous/intensity | forward voltage | if(mA) | |||
| min | max | min | TYP | min | max | |||
| high power LED 10W | red | 615nm | 630nm | 200lm | 400lm | 6.0 | 7.0 | 1200 |
| yellow | 585nm | 595nm | 200lm | 400lm | 6.0 | 7.0 | ||
| green | 515nm | 525nm | 400lm | 600lm | 9.0 | 11.0 | 1050 | |
| cyan | 490nm | 515nm | 400lm | 600lm | 9.0 | 11.0 | ||
| blue | 455nm | 470nm | 100lm | 200lm | 9.0 | 11.0 | ||
| white | 4500K | 10000k | 400lm | 600lm | 9.0 | 11.0 | ||
| warm white | 2500k | 4500k | 300lm | 500lm | 9.0 | 11.0 | ||
| POWER(W) | COLOR TEMPERATURE(K) | TEST CURRENT(mA) | light effect | chip | working voltage(V) | |||
| 10W | 2700-7000K | 1050mA | 80-100Lm/W | 3parallel 3series | 9V-10V | |||
| 20W | 2700-7000K | 700mA | 80-100Lm/W | 2parallel 10 series | 30V-36V | |||
| 30W | 2700-7000K | 1050mA | 80-100Lm/W | 3parallel 10 series | 30V-36V | |||
| 40W | 2700-7000K | 1400mA | 80-100Lm/W | 4parallel 10 series | 30V-36V | |||
| 50W | 2700-7000K | 1750mA | 80-100Lm/W | 5parallel 10 series | 30V-36V | |||
| 60W | 2700-7000K | 2100mA | 80-100Lm/W | 6parallel 10 series | 30V-36V | |||
| 70W | 2700-7000K | 2450mA | 80-100Lm/W | 7 series 10parallel | 30V-36V | |||
.Notes:
1.The unit price depends on the quantity, we can offer you at a competitive price.
2. Your inquiry related to our products or prices will be replied in 24hrs.
3 .Well-trained and experienced staffs to answer all your enquires in fluent English
4. OEM&ODM, any your customized lightings we can help you to design and put into product.
5. Distributorship are offered for your unique design and some our current models
6.Protection of your sales area, ideas of design and all your private information
Dongguan Youngsun Photoelectric Limited Company, a subsidiary corporation of Ping Jia Enterprise, specializing in manufacturing LED and LED lighting products, and a high-tech enterprise which set R & D, design and production as one. It has a plant area of 15,000 square meters,more than 400 employees.
We develop in strict accordance with ISO9001 quality assurance system.We have the stringent inspection and quality control system in every steps and the process of the materials from warehousing to the process design and to the product manufacturing.
With LED lighting skilled production and R & D capability, our products of all kinds of high-power LED, SMD LED, and in-line LED products have some good advantages, such as energy saving, environmental protection, good performance, high reliability and low lumens decay and long lifespan. Furthermore, we won the trust of customers due to our timely delivery so that we strive to become the domestic and the world's best manufacturer of LED light and contribute to innovation of human lighting.
At present, main foreign markets including Asia, Europe, America and Africa etc. We look forward to work together with more business partners and sincerely welcome domestic and foreign businessmen to negotiate business and design our blueprints for the corporate development and for our win-win benefit and common interest.
Our advantageous products include:DIP LED sources,LED STRIP,LED MINI MODULE,LED SIPLAY MODULE,LED STRING LIGHTS...
