P10 Led Module, Outdoor Waterproof P10 Red Led Sign Module, Popular Scrolling Programmable Led Sign

Dongguan Deying Photoelectric Co., Ltd.

US$ 5.24 - 6.35 MOQ: 1 Piece

Key Specifications

Model Number:

DY-P10

Chip Material:

InGaN

Emitting Color:

Red

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Model Number DY-P10

Chip Material InGaN

Emitting Color Red

Luminous Intensity 6500CD/㎡

Luminous Flux(lm) 20-22lm

Optical Attenuation(%) 80

Power Other

Power Dissipation 0.72

Color Rendering Index(Ra) 80

Color Temperature 6000-6500K

Operating Temperature(℃) -20, 50

Storage Temperature(℃) -35, 85

Place of Origin Guangdong, China

Brand Name DY

Certification CE

P10 led module, outdoor waterproof P10 red led sign module, popular scrolling programmable led sign

The technical parameter of P10 Display Module
Number	Item	P10 Single Red Module
1	Pixel pitch	10mm
2	Size of module(wxh)	320mm X160 mm
3	Resolution of module (wxh)	32 dots X16 dots
4	Density of pixel	10000dots/m²
5	Pixel configuration	1R or 1G or 1B or 1W
6	Red wavelength	625±2nm
7	Green wavelength	525±2nm
8	Blue wavelength	470±2nm
9	Colors	Red
10	Best viewing distance	10-100m
11	Horizontal viewing angle	120°
12	power consumption	200w/m²
13	Brightness	>2500cd /m2
14	Gray scale	16bits per color
15	Color temperature	5500k
16	Control method	Synchronization & Asynchronization
17	Driving method	1/4 scanning
18	Frame frequency	60Hz
19	Refresh frequency	>300Hz
20	Working voltage	AC220V/110V±10%
21	IP grade	IP65
22	Working temperature	-20°C~80°C
23	MTBF	>10000 hours
24	Lifespan	>100,000 hours
25	Defects rate	≤0.00001(Led display line standard<0.0001)
