5KV Composite Long Rod Suspension Insulator
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Mingneng
Model Number:
FXBOW-5/70
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Voltage Surge Arrester 110KVNegotiableMOQ: 100 Pieces -
10KV 5KA Zno Surge ArrestersNegotiableMOQ: 50 Pieces
-
Building Connection Lightning Arrester / Surge ArresterNegotiableMOQ: 100 Pieces
-
Cross-arm Composite InsulatorNegotiableMOQ: 100 Pieces
-
Types of Lighting Surge ArresterNegotiableMOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
Mingneng
Model Number
FXBOW-5/70
Type
Insulator
Material
Composite Polymer
Application
High Voltage
Rated Voltage
1~5KV
Tensile Strength
70KN
Specifications
Rated Voltage:1~5KVIdeal replacement of porcelain insulators
Certification:ISO9001:2008
With grading Ring and metal fitting
Materials:
1) Silicon Rubber for sheds/ housing
2) Glass-fiber reinforced epoxy resin rod (ECR type) for core
3) Hop dip galvanized cast steel for metal fittings
Technical Parameter:
Normal service conditions:
The ambient air temperarture is no higher than +40 degree. no lower than -40 degree.
The altitude above sea level does not exceed 2000m
Power frequency 48Hz~62Hz
Maximum wind speed does not exceed 35m/s
The earthquake intensity does not exceed 7 degrees
The voltage that long-time exerted shouln't exceed its Max MCOV
