IEC60332-1-1 Single Vertical Insulated Wire Flame Chamber Tester

IEC60332-1-1 Single Vertical Insulated Wire Flame Chamber Tester thumbnail-1
IEC60332-1-1 Single Vertical Insulated Wire Flame Chamber Tester photo-1
US$ 1,000 - 3,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Auto
Model Number:
Auto-DZ
Contact Supplier Request Quote Chat Now
Shenzhen Autostrong Instrument Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Auto
Model Number Auto-DZ
Power Electronic
Usage Auto Testing Machine

Specifications

IEC60332-1-1
Single Vertical Insulated Wire Flame Chamber Tester
1.One Year Warranty;
2.3-side stainless steel chamber;

IEC60332-1-1 Single Vertical Insulated Wire Flame Chamber Tester



Introduction:

Resistance of a single vertical electrical insulated conductor or cable to a vertical flame propagation under fire conditions.



Stainless steel screen with a sliding burner handle support for approaching or moving back the flame from the sample under test according to the CEI standards for test on cables.



Technical Specification:



Flame standard

IEC60695-11-2,1kw nominal pre-mixed flame

Burner Tube

IEC60695-11-2 Figure A

Burning Angle

45°

Thermocouple

Type K (Ni/Cr - Ni/Al),200°~1050°

Thermocouple Size O/D

0.5mm

Temperature Resolution

1ºC

Standard Copper Block

weight 10 ± 0 .05 g before drilling. Cu-ETP

Gas Supply

Propane,min.95% purity

Input Power

220 V 50 Hz 3A or 115 V 60HZ  Optional

Inner Dimensions

W*D*H=300mm*450mm*1200mm

Conform to standard

IEC60332-1-1,IEC60332-1-2,IEC60695-11-2
