Home > Instruments & Meters > Test Instrument > Test Machine > Cable Horizontal and Vertical Flammability Tester UL1581
Cable Horizontal and Vertical Flammability Tester UL1581
US$ 6,300 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
AUTOSTRONG
Model Number:
AUTO-DXSP
Payment & Shipping
Payment Methods:
Port of Shipment:
SHEN ZHEN OR HONG KONG
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fire Test Equipment as per IEC 60332-1US$ 1,000 - 3,500MOQ: 1 Set -
Lab Equipment Single Vertical Insulated Wire Flame Chamber TesterUS$ 1,000 - 3,500MOQ: 1 Set
-
Single Wire or Cable Vertical Flame Testing EquipmentUS$ 1,000 - 3,500MOQ: 1 Set
-
CEI EN 60695-11-2 Cable Vertical Flame Test EquipmentUS$ 1,000 - 3,500MOQ: 1 Set
-
CEI EN 60332 Cable Vertical Flame Test EquipmentUS$ 1,000 - 3,500MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
AUTOSTRONG
Model Number
AUTO-DXSP
Power
Electronic
Usage
Other, cable flammability teser
Cable Horizontal and Vertical Flammability Tester UL1581
1.Introduction:
Cable Horizontal and Vertical Flammability Tester is strictly designed and manufactured according to UL1581 and other similar international standards.It mainly used to test wire,cable or flexible cord UL1060 vertical flammability test,FT1 test,1061 cable flammability test,1080VW-1(vertical sample)flammability test,1090 electrical-line horizontal flammability tester and 1100 horizontal sample/FT2 flammability tester to evaluate wire,cable or flexible cord fire spread to nearby combustible material's ability.
2.Technical Parameters:
| Timer Device | 9999*0.1s |
| Flammability angle |
0°,20° |
| Flame Standards | ANSI/ASTM D 5207 & UL 1581 |
| Burner Standards | ANSI/ASTM D 5025 |
| Temperature | MAX 1050°C |
| Gas-Flow Rate | ml/min ±0.1% |
| Thermocouple | NiCrφ0.5 ±0.1% |
| Flame Test |
225W/50mm(16.5mm)/84±2S 405 ±10mL/min& 45±5 mm water 500W/125mm(40mm)/54±2S A:965 ±30mL/min&125±25 mm water B:385 ±15mL/min&552±100 mm C:300 ±10mL/ min&600±125 mm |
|
Temperature Controller |
16A/D ±0.05% |
| Cooper Weight | 10 ± 0 .05 g (before drilling) |
| Gas | purity>98% methane |
| Chamber Volume | > 4 cube |
