Specifications
1. one year warranty2. factory price
3. OEM/ODM
4. ISO17025 is free
Flexible Pipe Winding Test Device
To determine the mechanical strength of sealed lighting chains, in accordance with the IEC60598-2-20 Fig 3 and clause 20.6.14.
Wind the pipe on a cylinder of 250 mm diameter with a pull of 60 N for the number of operations and at the ambient temperature given below:
For chains having an IP number up to and including 20 10 times at 25 ° C ± 5 ° C
For chains having an IP number over 20 10 times at 25 ° C ± 5 ° C
Followed by 10 times at 15 ° C ± 5 ° C
Standard Outfit:
1 supporting frame, for supporting 1 cylinder, diameter 250 mm, and material of wood,
1 weight, 60 N.
Advantages:
1. 1 year warranty
2. ISO17025 is free offered
3. ILAC and CNAS can be offered if required
4. ISO9001, CE , ROHS, SGS certification
5. Our export products are in English data, no chinese.
6. For machines , we can offer video for customer reference
AUTOSTRONG is one of leading enterprises in Hong Kong specialized in the R&D and manufacture of testing instruments, with more than 60 researchers from foreign countries, Hong Kong and Mainland China.
AUTOSTRONG supplies standard or customized solutions and products for many tests, measurements and quality control tasks required in the field of cable, wire, socket, plug, switch, plastic and rubber testing.All of our products are complying with the requirements of many standards, such as IEC, UL, VDE, VS, JIS, GB and so on.
