Specifications
UL 1581 Vertical Wire Flame Test Apparatus1.For Cable and Wire tesing
2.English operation system;
3.1year warranty
cable and wire test instrument UL 1581 Vertical Wire Flame Test Apparatus:
1.Longterm supply
2.English operation system;
3.High Quality
4.According to the Standards: UL1581,ANSI/ASTM D 5207
Introduction:
UL 1581 Vertical Wire Flame Test Apparatus (Cable Horizontal and Vertical Flammability Tester) is strictly designed and manufactured according to UL1581
and other similar international standards.It mainly used to test wire,cable or flexible cord 1060 vertical flammability test,FT1 test,1061 cable flammability test,1080VW-1(vertical sample)flammability test,1090 electrical-line horizontal flammability tester and 1100 horizontal sample/FT2 flammability tester to evaluate wire,cable or flexible cord fire spread
Technical parameters:
| Timer Device | 9999*0.1s |
| Flammability angle |
0°,20° |
| Flame Standards | ANSI/ASTM D 5207 & UL 1581 |
| Burner Standards | ANSI/ASTM D 5025 |
| Temperature | MAX 1050°C |
| Gas-Flow Rate | ml/min ±0.1% |
| Thermocouple | NiCrφ0.5 ±0.1% |
| Flame Test |
225W/50mm(16.5mm)/84±2S 405 ±10mL/min& 45±5 mm water 500W/125mm(40mm)/54±2S A:965 ±30mL/min&125±25 mm water B:385 ±15mL/min&552±100 mm C:300 ±10mL/ min&600±125 mm |
|
Temperature Controller |
16A/D ±0.05% |
| Cooper Weight | 10 ± 0 .05 g (before drilling) |
| Gas | purity>98% methane |
| Chamber Volume | > 4 cube |
Package:
- 1piece per wooden case
High qualitty,Long life time and Competitive price
Best after service:Professional R&D and technical team support,can provide OEM & ODM service and overall laboratory solutions
Strict quality control and1year warrant
Short leadtime and fast delivery
With CE,ROHs,SGS and ISO certificates
ILAC &CNAS can be offered if required
ISO17025 is free offered
AUTOSTRONG is one of leading enterprises in Hong Kong specialized in the R&D and manufacture of testing instruments, with more than 60 researchers from foreign countries, Hong Kong and Mainland China.
AUTOSTRONG supplies standard or customized solutions and products for many tests, measurements and quality control tasks required in the field of cable, wire, socket, plug, switch, plastic and rubber testing.All of our products are complying with the requirements of many standards, such as IEC, UL, VDE, VS, JIS, GB and so on.
AUTOSTRONG have established stable cooperative relationship with many famous international company,laboratory and authorized third party test house. Such as: WAZAU, PTL, Bureau Veritas, TüV Rheinland, TüV Product Service, SGS, CSA international,Intertek, PSE Japan, UL Laboratory Sweden,Met Laboratory Inc, LG Korea, Samsung Electric
If you have any questions or you need more details ,kindly cotact me by trademanager or email for further discussion,thank you for your visiting.
