IEC60332 Stainless Steel Single wire flame chamber
for wire flammability test
Single Wire flame chamber:
1.Fast delivery and low price
2.Best selling,quality proved
3.Easy operation
4.High quality
Introduction:
Resistance of a single vertical electrical insulated conductor or cable to a vertical flame propagation under fire conditions.
Stainless steel screen with a sliding burner handle support for approaching or moving back the flame from the sample under test according to the CEI standards for test on cables.
Technical Specification:
Flame standard |
IEC60695-11-2,1kw nominal pre-mixed flame |
Burner Tube |
IEC60695-11-2 Figure A |
Burning Angle |
45° |
Thermocouple |
Type K (Ni/Cr - Ni/Al),200°~1050° |
Thermocouple Size O/D |
0.5mm |
Temperature Resolution |
1ºC |
Standard Copper Block |
weight 10 ± 0 .05 g before drilling. Cu-ETP |
Gas Supply |
Propane,min.95% purity |
Input Power |
220 V 50 Hz 3A or 115 V 60HZ Optional |
Inner Dimensions |
W*D*H=300mm*450mm*1200mm |
Conform to standard |
IEC60332-1-1,IEC60332-1-2,IEC60695-11-2 |
If you have any questions or you need more details ,kindly cotact me by trademanager or email for further discussion,warmly welcome to visit our factory.Thank you for your visiting.
