Specifications
CFR Part: 1500. 51- 53; ASTM D1776; ASTM PS79 -96, ASTM F963, EN71, ISO 8124, GB6675Application
To define the garments manufacturer responsibilities and duties to ensure that snaps are applied appropriately to all garments. To prevent separation between the snap and the garment, this represents a dangerous situation if the loose snap is swallowed by an infant.
The assessment of snap attachment strength is an important criterion especially in the design and manufacturer of garments for infants’ and children wear. The measurement of an uniform force applied to the snap attachment shall be recorded by means of a force-measuring device. (in this case an Imada Push/Pull Scale is utilized). Once the appropriate force is registered on the Imada Scale, a stop clock is used for recording a set period of time.
Specifications
Snap tester 30kg package
A, Forace gauge FB-30K: Display force up to 30kg capacity (100lb options)
B, Bench top satnd plate: Accurate force application
C, Lower fabric clamp: To grip fabric sample with constant force to aviod slippage
E, Calibration weight 15lbs: To verifty the accuracy of force gauges
F, Upper snap clamp: For female snap parts
G, Upper stud clamp: For male snap parts
H, Lower grasp button kit: Accessory for Lower Fabric Clamp for jean buttons and larger buttons up to 30 ligne
I, Upper Grasp Button Kit: For jean and four-hole buttons
Advantages:
1. 1 year warranty
2. ISO17025 is free offered
3. ILAC and CNAS can be offered if required
4. ISO9001, CE , ROHS, SGS certification
5. Our export products are in English data, no chinese.
6. For machines , we can offer video for customer reference
AUTOSTRONG is one of leading enterprises in Hong Kong specialized in the R&D and manufacture of testing instruments, with more than 60 researchers from foreign countries, Hong Kong and Mainland China.
AUTOSTRONG supplies standard or customized solutions and products for many tests, measurements and quality control tasks required in the field of cable, wire, socket, plug, switch, plastic and rubber testing.All of our products are complying with the requirements of many standards, such as IEC, UL, VDE, VS, JIS, GB and so on.
