toy testing machine EN71 ASTMF963 toy sharp edge tester

Wooden case

Specifications

EN71 ASTMF963 toy sharp edge tester
1.Conform to EN71 ASTMF963
2.Toy testing machine

toy testing machine  EN71 ASTMF963 toy sharp edge tester:



Introduction:





Toy Sharp edge tester confirms to the standard of ASTM F963 and EN-71. It is used to check whether the Children Products like the toys have the sharp edge which may hurt the children under 36 months.



Feature:



It is easy to carry for its small size.
It can be fixed quickly. So it is convenient to use it at any place in any time.
There are three testing switches of this device. Handle switch is use when the device is not fixed while the Panel switch and Foot Switch are used when the device is fixed.
There are two ways to ensure the torque. Both the pointer and the pilot lamp will display the value of the torque. Thus the accuracy of the torque can be achieved.
Size:L*W*H=180mm*120mm*160mm



Instrument configuration:



Main engine
Simulated Finger
Foot Switch
Gummed paper for the sharp edge test
Power Adapter
Aluminum toolbox





Testing procedure:
1. Fix the testing sample and make sure the edge of the samples can not be moved or bended.
2. The thickness of overlapping gummed paper cannot exceed 0.1 inch.
3. The angle of the tester and the edge of the sample is 90°±5°.
4. The testing position should be the sharpest parts of the sample.
5. The force should be adjusted to 1.35LBS.
6. Use the ruler to measure the cut length. If the length exceeds 0.5 inch, the edge is the sharp one.









  Package: Wooden Case



Shipping Method: Express/By Air/by Sea

• High qualitty,Long life time and Competitive price
• Best after service:Professional R&D and technical team support,can make OEM & ODM order,and also can provide overall laboratory solutions.
• Strict quality control and 1year warrant
• Short leadtime and fast delivery
• With CE,ROHs,SGS and ISO certificates
• ILAC and CNAS can be offered if required
• ISO17025 can be free offered
• Fast response to your any inquires.
