Specifications
Calibration NFC613-14 Plug Gauges for laboratory appliance;ISO17025 calibration certificates;
ISO9001 cerified factory suppli
Calibration NFC613-14 Plug Gauges for laboratory appliance
Application:
Autostrong offers a wide range of gauge to meet the most common standards including those from IEC,EN,UL,GB,DIN,VDE and other similar international standards.Such standards require the checking of size &definition etc,these gauges are constructed from senior stainless steel and appropriate steel with a hardnessof at least 60HRC and a roughness according to standard
require.
French Standards Test Gauge is strictly designed and manufactured according to the relevant standard requirements of NFC 61314.
This plug and socket test gauge is mainly used to test and inspect whether the structure and size of plugs and sockets conform to NFC61314 standards. And the mainly application industries is electronics, electrical appliances, plugs and sockets and other similar areas.
Specification:
NFC613-14/C1 |
Gauge for checking impossibility of single-pole insertion of plugs (6A/16A) |
NFC613-14/C2 |
Gauges for size of entry holes for plug pins (5.3mm/5.8mm) |
NFC613-14/C3A.B.C |
Gauges for distance to point of first contact ( 5.75/5.0/5.25mm, 6A; 5.45/5.60/5.75mm, 16A) |
NFC613-14/C4A.B.C |
Gauges for minimum opening contact tubes (3.94mm, 300/150g; 3.80mm, 400/200g; 4.60mm, 400/200g) |
NFC613-14/C5 |
Gauge for acceptance of two-pole plugs (6A/16A) |
NFC613-14/C6 |
Gauge for maximum opening of contact tubes(16A) |
NFC613-14/C7A.B |
Gauge for pin spacing(6A/16A) |
VDE0620-1 plugs and socket -outlets adaptors
NFC613-14 gauge list
