Home > Products > Thermal Printer > Pos mainboard pos machine
Pos mainboard pos machine
- 1000 Piece / Pieces per Month
- SHENZHEN
- T/T Credit Card
- Hot Sale Android Cashless POS Payment BUS Fare Collection System with RFID Card QR Code Reader
- Android System Bus Validator GPS NFC RFID Bus Card Reader with QR Code Payment
- RFID Bus Ticket Reader Prepaid NFC Card POS Bus Payment System to Automatic Fare Collection
- Payment System QR Code Scanner NFC Bus Card Reader Ethernet
- 5 Inch TFT Color Display Ethernet Barcode Scanner Ticket Machine NFC Bus QR Code Scanner
- RS232, RS485 Interface CPU IC card 1D 2D Barcode Payment POS Terminal for Bus
Product Details
Place of Origin: | Guangdong, China | Brand Name: | TCANG | Model Number: | TC-EC-500 for EPSON MT-532 |
Product Description
Pos mainboard pos machine
M/B A-T500 Series | ||
Model | M-T510 Series | |
Printing Method | Thermal line | |
Paper Path | Curve or Straight or Drop in | |
Print Font |
| |
Font | Font A : 12 x 24 / Font B : 9 x 17 / Kanji : 24 x 24 | |
Column capacity | Font A : 36 columns | |
Character size | 1.25 (W) x 3.0 (H) mm (Font A) / 0.88 (W) x 2.13 (H) mm (Font B) | |
Character set | 95 Alphanumeric, 37 International, 128 x 11 Graphic | |
Interface | RS -232 / IEEE 1284 Bi-directional parallel, USB | |
Data buffer | 4KB | |
Print Speed (Max.) | 150 mm / sec. | |
Paper Dimensions | 57.5 ± 0.5 mm x dia. 254 mm max. | |
Paper Thickness | 0.06~0.15 mm (~ 0.18 mm for HF ) | |
Power | 24 VDC ± 2.4 V | |
Power consumption | Approx. 1.25 A(print duty 25%) | |
Operating Temperature | -15 to 70°C (without BA-T500 S eries ) | |
Reliability | MCBF | 37,000,000 lines |
Receipt printing | - | |
Printer life | Mechanism : 15,000,000 lines , Thermal head : 100 km (62.14 miles ) | |
Overall Dimensions | 102.9 (W) x 91.9 (D) x 57.5 (H) mm | |
Mass | Approx. 460 g | |
Power Supply (option) | PS -180 | |
Factory Options | Mark sensor, Autocutter Type | |
Model | M-T520 Series | |
Printing Method | Thermal line | |
Paper Path | Curve or Straight or Drop in | |
Print Font |
| |
Font | Font A : 12 x 24 / Font B : 9 x 17 / Kanji : 24 x 24 | |
Column capacity | Font A : 37 columns | |
Character size | 1.25 (W) x 3.0 (H) mm (Font A) / 0.88 (W) x 2.13 (H) mm (Font B) | |
Character set | 95 Alphanumeric, 37 International, 128 x 11 Graphic | |
Interface | RS -232 / IEEE 1284 Bi-directional parallel, USB | |
Data buffer | 4KB | |
Print Speed (Max.) | 150 mm / sec. | |
Paper Dimensions | 59.5 ± 0.5 mm x dia. 254 mm max. | |
Paper Thickness | 0.06~0.15 mm (~ 0.18 mm for HF ) | |
Power | 24 VDC ± 2.4 V | |
Power consumption | Approx. 1.25 A(print duty 25%) | |
Operating Temperature | -15 to 70°C (without BA-T500 S eries ) | |
Reliability | MCBF | 37,000,000 lines |
Receipt printing | - | |
Printer life | Mechanism : 15,000,000 lines , Thermal head : 100 km (62.14 miles |
