Pos printer mechanism pos system
M/B A-T500 Series | ||
Model |
M-T510 Series |
|
Printing Method |
Thermal line |
|
Paper Path |
Curve or Straight or Drop in |
|
Print Font |
|
|
Font |
Font A : 12 x 24 / Font B : 9 x 17 / Kanji : 24 x 24 |
|
Column capacity |
Font A : 36 columns |
|
Character size |
1.25 (W) x 3.0 (H) mm (Font A) / 0.88 (W) x 2.13 (H) mm (Font B) |
|
Character set |
95 Alphanumeric, 37 International, 128 x 11 Graphic |
|
Interface |
RS -232 / IEEE 1284 Bi-directional parallel, USB |
|
Data buffer |
4KB |
|
Print Speed (Max.) |
150 mm / sec. |
|
Paper Dimensions |
57.5 ± 0.5 mm x dia. 254 mm max. |
|
Paper Thickness |
0.06~0.15 mm (~ 0.18 mm for HF ) |
|
Power |
24 VDC ± 2.4 V |
|
Power consumption |
Approx. 1.25 A(print duty 25%) |
|
Operating Temperature |
-15 to 70°C (without BA-T500 S eries ) |
|
Reliability |
MCBF |
37,000,000 lines |
Receipt printing |
- |
|
Printer life |
Mechanism : 15,000,000 lines , Thermal head : 100 km (62.14 miles ) |
|
Overall Dimensions |
102.9 (W) x 91.9 (D) x 57.5 (H) mm |
|
Mass |
Approx. 460 g |
|
Power Supply (option) |
PS -180 |
|
Factory Options |
Mark sensor, Autocutter Type |
|
Model |
M-T520 Series |
|
Printing Method |
Thermal line |
|
Paper Path |
Curve or Straight or Drop in |
|
Print Font |
|
|
Font |
Font A : 12 x 24 / Font B : 9 x 17 / Kanji : 24 x 24 |
|
Column capacity |
Font A : 37 columns |
|
Character size |
1.25 (W) x 3.0 (H) mm (Font A) / 0.88 (W) x 2.13 (H) mm (Font B) |
|
Character set |
95 Alphanumeric, 37 International, 128 x 11 Graphic |
|
Interface |
RS -232 / IEEE 1284 Bi-directional parallel, USB |
|
Data buffer |
4KB |
|
Print Speed (Max.) |
150 mm / sec. |
|
Paper Dimensions |
59.5 ± 0.5 mm x dia. 254 mm max. |
|
Paper Thickness |
0.06~0.15 mm (~ 0.18 mm for HF ) |
|
Power |
24 VDC ± 2.4 V |
|
Power consumption |
Approx. 1.25 A(print duty 25%) |
|
Operating Temperature |
-15 to 70°C (without BA-T500 S eries ) |
|
Reliability |
MCBF |
37,000,000 lines |
Receipt printing |
- |
|
Printer life |
Mechanism : 15,000,000 lines , Thermal head : 100 km (62.14 miles |
|
