E-mail or telephone to negotiate specific prices.
PRODUCT DESCRIPTION:
The model combines the multi-layer coextrusion, computers, electro-hydraulic proportional control and frequency conversion and other advanced technology, high degree of automation machine, stable and efficient operation, high production efficiency, head plasticizing performance reached the international advanced level, suitable for production ofIt looks beautiful, high strength, good barrier properties, corrosion resistance, anti-leakage, high-performance multilayer composite plastic hollow containers.
SPECIFIC PARAMETERS:
system |
Project |
3000L-3Layers |
Specification |
Material |
HMWHDPE/PE/PP/HDPE |
Max. capacity of product |
3000L |
|
Dimensions |
12m*4.5m*7.2m |
|
Total weight |
65ton |
|
Extrusion system |
Dia. Of screw |
100mm grooved barrel(inner) |
110mm grooved barrel(middle) | ||
100mm grooved barrel(outer) | ||
L/D ratio of screw |
32:1 |
|
Machine barrel screw material |
38CRMOALA |
|
Maximum extrusion |
60RPM |
|
Drive motor |
75KW(inner) |
|
75KW(middle) | ||
75KW(outer) | ||
Heating power |
110KW |
|
Clamping system |
Max. size of mould |
1900*2300mm |
Distance between platens |
1000mm |
|
3500mm | ||
Clamping force |
2200KN |
|
The thickness of the mold |
1000-2200mm |
|
Die |
The die material |
38CRMOALA |
Capacity of accumulator |
110L |
|
Heating power of die |
90KW |
|
Quantity of die heating zones |
10zones |
|
The energy consumption |
Motor power of oil pump |
45KW |
Total power |
350KW |
|
Average energy consumption |
250KW |
|
Air pressure |
0.8MPa |
|
Water pressure |
0.3MPa |
APPLICATION:
Packaging:A Packed by wooden pallet
B Wrapped with film
C Fixed into container
Shipping:4-month working days after having downpayment.
