IEC EN 60695-11-2 3 4 Electronic Power and Deformation Testing Machine Usage Cable Vertical Flame Test Equipment
Introduction:
When there is a fire around the products, should ensure that it will not to cause the spread of the fire, horizontal-vertical burning test simulates electronic products around the environment in the early condition, using the simulation technology to assess the fire risk. The test equipment apply to the electrical and electronic product components of household appliances, spare parts and components, such as: household appliances insulation shell, Panel switches, printed circuit boards and insulation materials and so on.
Kinds |
500W(5V class ) | 50W(HB/Vclass) |
| Test Flame | 500W(burning test for V-0,V-1,V-2 classification) | 50W(burning test for V-0,V-1,V-2 classification) |
| Burner Tube | Internal diameter: Φ 9.5mm±0.3mm | Internal diameter: Φ 9.5mm±0.3mm, |
| Burning Angle | 0°,20°,45° | 0°,20°,45° |
| Thermocouple | Type K (Ni/Cr - Ni/Al) | Type K (Ni/Cr - Ni/Al) |
| Thermocouple Size | 0.5 mm | 0.5 mm |
| Standard Copper Block |
9mm±0.01mm, weight:10g±0.05g before drilling. |
5.5mm±0.01mm, weight:76g±0.01g before drilling. |
| Time for Temperature to Increase | From 100°C±5°C to 700°C±3°C; 54s±2s (preset) |
From 100°C±5°C to 700°C±3°C; 44s±2s (preset) |
| Gas Flow | 965±32ml/min | 105±10ml/min |
| Gas Supply | methane,min.98% purity | methane,min.98% purity |
| water-column | 125m±5mm | ‹10mm |
| Test Time | 54±2s | 44±2s |
| Flame Height Indicator | 40±1mm | 20±1mm |
| Volume Of Chamber | >0.5m³, black interior | >0.5m³, black interior |
| Conform to standard | UL94,IEC60695-11-3,IEC60695-11-20 | UL94,IEC60695-11-4,IEC60695-11-10 |
According to the price and efficiency,choose the best transportation for you.
1. High quality is always our key to market .
2. We will take photos or vidios of your order before shipment.
3. Engineering team is professional and will provide you with good after-sales service.
The advantage of our company
1. Professional R&D team and factory can offer our clients OEM&customizing service.
2. Delivery time is fast, and quick respond.
3. Many years of experience in foreign export.
Management philosophy
1) Customers are god. We will do our best to satisfy you.
2) We will protect our reputation.
3) The quality is the most important thing.
4) We will bear a strong sense of responsibility.
HONGKONG AUTOSTRONG TECHNOLOGY CO,.LTD is a high-tech company in Hongkong,who is engaged in research and development,manufacture of test instrument,whose headquater is in Kowloon,Hongkong,with branch offices in Shenzhen.
AUTOSTRONG is one of leading enterprises in Hongkong on R&D and manufacture of testing instruments.we supply standard or customized solutions and products for many test,measurement and quality control tasks required in the world of cable,wire,socket,plug,switch,plastic and rubber testing.All of our products are complying with the requirements of many standards,such as IEC,UL,VDE,VS,JIS,GB and so on.
AUTOSTRONG strategic cooperation with Germany WAZAU,Germany PTL company,Germany FISCHER,Japanese minebea,and on going technical exchange.
AUTOSTRONG spirit:integration of science and wisdom,quality and service co-exist,face to the world,to achieve a win-win for the supply and demand.
After-sale Srevices
--1 year warranty service
--reply within 48 hours and solution provide within 3 working days
--Operation video and English operation manual
--Technical Egineer are avalible for oversea trainning
--Remote control technical consult
--Maintenance plan
Good Packaging:
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
Why Choose Us?
1.We are professional test equipment manufature in china,has excellent experience.
2.We have advanced machine equipment, cost savings.
3.We supply 24 hours online service to slove your every question.
4.We have the best knowledge about the drying machine in USA,UK,CANADA,SOUTH AFRICA,INDIA,AUSTRALIA,ETC.
For any more information, please fill it in the box below, we are always at your service.
