IEC60335 water spillage apparatus
Introduction:
- This spillage tester(water spillage test apparatus) is designed and manufacture according to IEC 60335-2-24 and IEC60335-2-89 clause 15 figure 101 and other similar international standards.
- It is used for for testing refrigerating appliances and consists of the vessel, removable bridge support, release pin, and displacement block.
| Displacement block volume | 140 ml ± 5 ml |
| Displacement block mass | 200 g ± 10 g |
| Displacement block dimensions | 112X50X25mm |
| Approximate overall dimensions | 15.5X7.3X6.3CM |
| Reference | IEC60335-2-89 clause 15 figure 101 |
| Material | nickel plated brass |
| The dimensions of the vessel are inside dimensions and the torlance on inside dimensions is ± 2mm. | |
Packading&Shipping
Packed with carton box express/by air/by sea
