Help Center600 W Laser Metal Cutting Machine
Related Products
-
New Product AD Laser Welding Machine on Rings for Advert Industry With High QualityUS$ 5,000 - 15,000MOQ: 1 Set -
New Product AD Laser Welding Machine on Bracelet for Advert Industry With High QualityUS$ 5,000 - 15,000MOQ: 1 Set
-
New Product AD Laser Welding Machine on Iron Chain for Advert Industry With High QualityUS$ 5,000 - 15,000MOQ: 1 Set
-
New Product AD Laser Welding Machine on Exterior Billboards for Advert Industry With High QualityUS$ 5,000 - 15,000MOQ: 1 Set
-
New Product AD Copper High Efficiency Laser Welding Machine for Eye Glasses Frame Industry With High QualityUS$ 5,000 - 15,000MOQ: 1 Set
Specifications
Laser Metal Cutting Machine:1. imported laser tube;
2.cutting metals
3.high speed
3. Working principles:
Cutting is achieved by powerful laser focused on object to cause instant melting and evaporation, with xenon lamp as the generator. Automatic cutting is controlled by digitalized mechanic system.
4. Product performance indices:
1). Higher cutting speed and low cost, operation safe and stable function.
2). Smooth and fine edge or surface and small distortion.
3). Imported servo motor and gearing system to guarantee precise cutting
4). Dedicated software enables graphic or text to be instantly designed or processed. Flexible and easy operation.
5). Laser beams can be diversified to achieve multi-spots or multi-beams focused on welding.
5. Product application:
Cutting on metal or non-metal plates or tubes, special for S/S plate, iron plate, aluminum, ceramic, silicon chip, and diamond cutting. Widely used in industries of metal, glasses, precise mechanics, hardware productions, steel structuring, vehicle parts, decorations, posters etc.
6. Technical Parameter:
Model |
HB-600W |
Laser Power |
600W |
Laser Wavelength |
1064nm |
Total power consumed |
20KW |
Power supply |
380V/50Hz/60Hz/60A |
Pulse Frequency |
1-500Hz |
Pulse Width |
0.1-20ms |
Positioning |
Red dot |
Max Cutting speed |
3000mm / min |
Cutting Size |
1300*2500mm |
Repeat positioning accuracy |
0.08mm |
Max Cutting thickness |
≤9 mm |
Continuous Working Time |
24 hours |
Control System |
Professional CNC software |
Cooling mode |
Water cooling |
7. Cutting Samples:
