Specifications
1) Laser cutting machine2) CE, FDA certificate
3) high power
4) stainless steel cutting
5) Aluminum, mild steel, brass
YAG Laser Metal Cutting Machine 600W
Applied Fields
Laser Metal Cutting machine is widely used in hardware, precise machinery, automobile components, glasses clocks and watches, precise cutting, medical equipment, instrument and other metal related industry. It can carry on non-contact cutting on metal sheet, pipe, especially for stainless steel, steel plate, diamond saw blades and other metal materials, it has excellent processing for the various high-brittle hard alloys. In the lines of hardware and metal sheet industries, laser cutting technology can be partially replace the line cutting.
Features
The laser of HB-500W laser cutting machine adopts the current most advanced laser technology manufacturers from Germany, the UK imports dedicated laser cavity, it have the merits of effect cooling and high electro-optical conversion efficiency. In structure, the machine have a great improvement—the entire optical system adopts an enclosed struature, it has functions of optical previewing and focus instructing with a more aesthetic appearance and more convenient operation. The machine is equipped with the latest external water cooling system with very low running noise and high accuracy temperature regulator, which provide a reliable guarantee for a long time running.
Technical Parameter
Model: |
HB-600W |
Laser material: |
Nd: YAG crystal |
Laser wavelength |
1064nm |
Cutting size |
1300*2500mm/ 1500*3000mm (optional) |
Cutting thickness |
≤ 9mm |
Max. cutting speed |
3000mm/min |
Min. linear width |
0.15mm |
Repetition accuracy |
0.10mm |
Pulse width |
0.1-20ms |
Pulse frequency |
1-500Hz |
Location |
Red light |
Power consumption |
≤ 20KW |
Power |
380V/50Hz/60Hz/60A |
Chiller |
Water cooling |
Machine size |
5000×2000×1800mm |
Chiller size |
750×560×900mm |
Cutting Samples
