Simple lifting type cubic parking garage,vertical lifting type parking system
Car Parking System/Vertical Lift Cubic Parking equipment
It’s a new type of vertical lifting and horizontal sliding parking equipment, that combined advantages of vertical lifting type and Parallel Conveyor type. Lifting & sliding & revolving are carried at the same time for saving time of parking and storage. This kind equipment can be set quickly to realize fast access. With simple operation and intelligent management, it comes into widespread use. It reaches security, reliability and green environmental parking spaces.
Advantage Car Parking System/Vertical Lift Cubic Parking equipment
1) Flexible, vertical cycle series parking system covers small area, flexible, and can be set up independently,
also can be attached into building, also can be more than one combination,small vertical cycle series parking equipment can be Installed in the living area, beside the building, save the land space.
2) Rapidly, parking car and taking car out in short time.
3)Economically,build vertical type parking system can save the considerable cost of purchasing land, conductive to the rational planning and optimize the design,improve the comprehensive economic benefit.
4) Save electric power, vertical circulating mechanical parking system typically does not require forced ventilation, no large-area lighting, power consumption only 35% of the common underground parking garage.
Working principle
When in, the car drives on the platform of the lifter on the ground that will lift the car in the storey of the parking space to complete the in-garage process; Conversely for out of the garage, meaning the horizontal side-sliding driving machine will send the parking space to the lifter on the ground that place the car on the ground.
Structure and sizes
Vertical Lifting Model | |||
Item |
Specification |
||
Car Dimension*Weight |
≤5000mm*1850mm*1550mm*1700kg |
||
Car no. |
20-25 per set |
||
Power |
Lifting power |
Transverse power |
Rotary table power |
37kw |
0.75kw |
2.2kw |
|
Speed |
Lifting speed |
Transverse speed |
Rotary speed |
60~90m/min |
25m/min |
3r/min |
|
Voltage |
380v/50hz/3phase |
||
Lifting model |
Hoist+steel wire rope |
||
Control system |
PLC |
||
Operation model |
Slot card+digital button+Touch screen |
||
Safety device |
1.entering indicator light 2.emergency lighting 3.in-checking 4.out-checking 5.emergency switch 6.checking sensor 7.guiding device |
||
Main Systems:
The Elevator System:
The elevator is in charged of the lifting movement of the vehicles,which mainly composed by steel structure,carriage,counter weight,drive system,guide devices,safety protection devices.
The Entrance & Exit System:
It mainly includes automatic door, turn table, scanning device, voice prompts etc, that ensure the safety of users and cars, and fast accurately find the vehicle.
Vertical cycle series parking working site photo
Packaging:steel frame with plastic wrap cover
Shipping:With 1-2monthes after deposit
Warranty:2years
Within 2years,we will send the spare parts to u for free once sothing wrong with parking system.
Service Features
I-"Complete & Integrated park solutions"
1.Excellent before-sales services
2.Flexiable garage design
3.Customized solutions
4.Manufacturing reliable products
5.Fast delivery-quick installation-final test
6.Trustworthy support and maintenance
II- "One to one lifetime close service"
1. "One to one"--Provide every customer 1 service consultant, through 12 service stations.
2. "Lifetime"--To the equipments, to the customers.
3. "Close"--Besides the related affairs, concerned about lives of customers,to form "close friend"
relationship.
III-"Long term win-win corporation"
1.With exceptional quality,win the customer's credit & reliablity.
2.Offer customers all-around tailor-made solutions to satisfy user's diverse requirements, build
long-term corporation,accumulate rich experience.
Installation
If necessary,we will send our engineer oversea to help you install.You need pay for the round
trip ticket fee,and also need to pay USD50/man/day for the engineer as labour fee.
Shandong Jiulu Parking Equipment Co.,ltd. Company Introduction
Shandong Jiulu Parking Equipment Co.,ltd.Mainly engaged in:”QTZ series tower crane,SC construction elevator,
passenger elevator,material hoist,Intelligent cubic parking garage, ZLP series suspended platform as well as
other construction machinery products,include R & D, manufacturing, sales and service.
