Master-Q deionized water system (Tap water inlet)
Master-Q series is popular superior choice of high performance for general analysis pure water. It has 2 kinds of output, 15 or 30 liters/hour. And the resistivity, reaching to 16-18.2MΩ.cm, is above of the grade I standard of GB6682-2008. It also meets the most requirements of chemical and biological experiments’ pure water.
Applications:
- Feed of ultrapure water system
- Glassware washing
- Microbiological analysis
- Sample dilution and reagent preparation
- Chemical and qualitative analysis
- Water analysis and universal HPLC
- Spectrum measurement
- Disposing of buffer, medium
- Feed of autoclave sterilizer, biochemical analyzer, immunoassay analyzer, constant temperature and humidity chamber, salt spray test chamber, dampening machine and etc.
Specification
| Model | Deionized water purification system | ||||
| Master-Q | Master-Q UT | Master-Q plus | Master-Q plus UT | ||
| Flow procedure | PF+KDF+AC+RO+AC | PF+KDF+AC+RO+AC | PF+KDF+AC+RO+AC | PF+KDF+AC+RO+AC | |
| +DI | +UV+DI+TF | +DI | +UV+DI+TF | ||
| Application |
.Ware washing .Agricultural expe .General biological expe .Aquatic products feeding .Inlet water for Ultra pure water machine .Inlet water for sterilizer/T&H chamber .Buffer disposing .Aseptic drinking water .Physical and chemical analysis .Fine chemistry industry .Inlet water for Ultra pure water machine .GC/HPLC .Pharmacy research .Medicine examining |
||||
| DI | Resistivity | 16-18.2MΩ.cm | |||
| water | Heavy metal | 0.1ppb | |||
| quality | TOC | 30 ppb | |||
| Bacteria | - | 1CFU/ml | - | 1CFU/ml | |
| Particle(>0.22µm) | - | 1/ml | - | 1/ml | |
| RO water quality | < TDS(ppm,mg/l) of tap water×5% | ||||
| Technical | Output(25°C) | 15 Liters/hour* | 30 Liters/hour | ||
| specification | Flow rate | 2 Liters/min(with pressure tank) | |||
| Pure water outlet | RO water, deionized water | ||||
| Dimension | L×W×H:50×36×54cm/20-30Kg | ||||
| weight | |||||
| Electric | AC110-220V,50/60Hz,120W | ||||
| requirements | |||||
| Control | Mode display |
Power on, program, inlet rinse, producing, full, circle, regular outlet, disinfection, consumables replacing remind |
|||
| system | Safety |
Low pressure and full water alarm, password, auto-reset, outlet forbidden when alarm or disinfection |
|||
| System monitor |
Monitoring quality of feedt water, RO water and ultrapure water, temperature, used and left time of consumables |
||||
| Feed water requirements | Tap water, inlet TDS<200 ppm,5-45°C,1.0-4.0kgf/cm2 | ||||
| (if inlet TDS>200ppm, extra pretreatment is recommended) | |||||
| Purification | Pretreatment unit |
5µm spun fiber filter×1+Kinetic degradation fluxion filter×1+Granular active carbon filter×1 |
|||
| system | RO unit | 100 GPD RO membrane×1 (Plus model: 100 GPD RO membrane×2) | |||
| Subsequent unit |
Post active carbon filter×1+Mixed bed resin cartridge×3 {Plus model: Mixed bed resin cartridge×4} |
||||
| UT model:+254nm wavelength UV cartridge×1+(0.45+0.2) µm terminal filter×1 | |||||
| Standard configuration | Main body(including:1 set cartridge)+4 gallon tank+ accessory box | ||||
Inlet water :TDS=200ppm, 25°C, 50psi and 15% recovery rate.
GPD=gallon per day 1gallon=3.78L.
The quality of inlet water will effect output’s and cartridge’s life.
PF:Pretreating, KDF:Kinetic degradation fluxion, AC:Active carbon, RO:Reverse osmosis, DI:Ion exchange, UV:Ultraviolet, TF:Terminal filter
This year Shipping shows:
As one part of Chincan Sales Group, each factory has technical support staffs available offering repair and maintenance of the products exported by Chincan. We promise that all of our products will be easily accessible to technical support and manufacturer's representatives who are always ready and able to assist when needed.
Established in 2004, Hangzhou Chincan Trading Co., Ltd. is a foreign trading company authorized by Chinese State Department of Foreign Economy & Trade and General Administration of Chinese Customs, which located in Hangzhou city, Zhejiang province, China.
We are a specialist company committed to exporting laboratory instruments, educational apparatus, medical & hospital equipments. With its superior performance, Chincan instruments are sold well throughout the Americas, Asia Pacific, the Middle East, Africa and Europe. With our excellent service, Chincan Trading has won a good reputation from the market.
Cooperative factories which qualified by Chincan come from many provinces and cities across China. All of them need to be ISO certified, Some products have CE.
Our customers spread all over the world, most products are very popular in Asia Pacific, Africa, Europe and South America,such as microscopes, autoclaves, shakers, incubators, baths, pH meters, spectrophotometers, pure water systems, balances, pipettes, centrifuges, viscometers, hardness testers, biological safety cabinets, etc.
We are doing our best to meet various needs of clients from different countries.
Our company website:
Q: What after-sales service can be provided by CHINCAN ?
A: The after-sales service of CHINCAN is divided into two parts: technical support and maintenance.
Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
Q: How to solve the disputes between CHINCAN and customers during the after-sales maintenance?
A: We will be customer oriented,and make concessions in some principles , we will properly handle the disputes to maximize customer's satisfaction.
Normally all CHINCAN products are supplied with a warranty of 12 Months from the date of shipment. This warranty is entirely dependent on the following conditions:
1.The following circumstance don't belong to the warranty policy which is Man-made damages caused by improper operations.
2.The instruments must be operated in accordance with our operating guidelines; serviced and maintained on a regular basis in accordance with the terms specified in the relevant user manual.
3. Only approved spare parts should be used in the instruments which bought from CHINCAN and these should be changed on a regular basis as specified in the relevant user manual. Details of the approved spare parts and accessories for each instrument are shown in the user manual or alternatively this information can be obtained from CHINCAN.
