50W Car Radio Long Range Walkie Talkie For TYT TH-9800 Long Range Transceiver
US$ 180 - 200
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
TYT car radio
Model Number:
TH-9800 car radio
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mobile Transceiver 65W TYT TH-9000D Single Band Car Radio Long Range TransceiverUS$ 90 - 100MOQ: 1 Piece -
QYT New Product KT-8900R Tri Band Transeiver DTMF 2Tone & 5tone Professional Mobile RadioUS$ 73 - 85MOQ: 1 Piece
-
NEW! QYT KT-8900 Dual Band Mobile Radio 25W 136-174/400-480mhz Car Radio TranseiverUS$ 63 - 70MOQ: 1 Piece
-
QYT Dual Band Mobile Radio KT-8900 25W 136-174/400-480mhzUS$ 63 - 70MOQ: 1 Piece
-
Car Radio 100km Long Range 50W Output TYT TH-9800 Quad Band Vehicle Radio Mobile Transceiver Quality ChoiceUS$ 180 - 200MOQ: 1 Piece
Place of Origin
Fujian, China
Brand Name
TYT car radio
Model Number
TH-9800 car radio
Type
Vehicle Mouted
Dimensions
140*42*168 mm
Frequency Range
RX/TX 26-33/47-54/136-174/400-470MHz
Storage Channel
809 Channels car radio
Talk Range
25-35km car radio
50W Car Radio Long Range walkie talkie For TYT TH-9800 Long Range Transceiver
Main Features:
1.CTCSS Tone/DCS Code Operation
2.Various Scanning
3.DTMF Signaling Operation
4.2 Tone & 5 Tone Signaling Operation
5.Auto Range Transponder System(ARTS) Operation
6. V+U/V+V/U+U Dual Band Operation
7. Automatic Repeater Shift(ARS)
8. 800 Memory channels
9. Quad Band Operation: 29/50/144/430MHz
10.Ultra-size LCD dual display screen
Product Description
50W Car Radio Long Range walkie talkie For TYT TH-9800 Long Range Transceiver
| General | ||
| Frequency range | Left Band | Right Band |
| RX |
26.000-33.000MHz, 47.000-54.000MHz, 108.000-180.000MHz, 320.000-512.000MHz 750.000-950.000MHz(except cell phone) |
134.000-180.000MHz, 400.000-512.000MHz |
| TX |
26.000-33.000MHz, 47.000-54.000MHz 134.000-174.000MHz, 400.000-480.000MHz |
134.000-174.000MHz, 400.000-480.000MHz |
| Modulation mode | F3E(FM) | |
| Antenna impedance | 50Ω | |
| Channel steps | 2.5/5/6.25/7.5/8.33/10/12.5/15/25/30/50/100KHz | |
| Rated voltage | 13.8V DC ±15% | |
| Operating Temperature | -20°C ~ + 60°C | |
| Frequency stability | 5ppm | |
| Current Consumption | RX:0.5A(Squelched) TX:8.5A | |
| Weight | 1.2kg | |
| Transmitting | ||
| Output power | 50/20/10/5W(29/50/144MHz) | |
| 40/20/10/5W(430MHz) | ||
| Maximum Deviation | ±5KHz | |
| Suprious Radiation | <-60dB(29MHz:<-50dB) | |
| Modulation distortion | <3% | |
| Microphone Impedance | 2kΩ | |
| Receiving | ||
| Intermediate Frequencies | 49.95KHz/450KHz(Left band) | 38.85KHz/450KHz(Right band) |
| Sensitivity(for 12dB SINAD) | <0.2μV | |
| Squelch Selectivity | <0.6μV | |
| Selective | 12KHz/30KHz | |
| Maximum AF Output | 2W @ 8Ω for 5%THD | |
Packaging & Shipping
50W Car Radio Long Range walkie talkie For TYT TH-9800 Long Range Transceiver
Packing Item
1×Transceiver
1×Microphone(with DTMF keypad)
1×Mobile Mounting bracket
1×DC power cable with fuse holder
1×Hardware kits
Remark: 1pc color box, 10pcs per carton
Carton size:45*52*37cm
