9 Inch Touchscreen Lcd Advertising Display
US$ 96 - 115
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangxi, China
Brand Name:
Flintstone or OEM
Model Number:
AD913WPT
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
7 Inch Lcd Point of Sale Touchscreen In-store DisplayUS$ 75 - 89MOQ: 1 Unit -
7 Inch Lcd Digital Menu Board With Motion SensorUS$ 50 - 55MOQ: 1 Piece
-
7 Inch Indoor Electronic Lcd Billboard Display With Motion SensorUS$ 50 - 55MOQ: 1 Piece
-
Indoor 10" Touch Lcd Digital Billboard ScreenUS$ 120 - 125MOQ: 1 Piece
-
Indoor 10" Lcd Wall Mount Touch Screen KioskUS$ 120 - 125MOQ: 1 Piece
Place of Origin
Guangxi, China
Brand Name
Flintstone or OEM
Model Number
AD913WPT
Type
TFT
Application
Taxi
Panel Size
198.0 (W) * 112.08 (H) (mm),9 Inch
Max Resolution
800 x 480 (H*V)
Viewing Angle
70°/70°/50°/60°(L/R/U/D)
Pixel Pitch
0.0825 (W) * 0.2335 (H) (mm)
Color
262K/16.2M (6bit/6bit+FRC)
Contrast Ratio
500:1
Brightness
200cd/m2
Response Time
4.5/12.5ms,<10ms
Input Voltage
AC100V-240V (50HZ-60HZ)
Specifications
1. Capacitive touch screen advertising player2. USB auto-upgrade
3. Timer function, auto play
4. IR (infrared) boby senso
Key Functions
1. A video will start playing when its corresponding icon is touched.
2. When the video playing is completed, the player will go back to normal loop playing.
3. Timer function: the player turns on / off at the same time everyday according to your setting.
4. Update contents of the memory card by simply inserting an USB flash drive.
5. By pressing a combination of function keys on the player, the function keys themselves can be disabled or enabled.
6. The player starts automatically when the sensor detects an approaching viewer.
Main Functions
1. A video will start playing when its corresponding icon is touched.
2. Built-in 9 inch TFT LCD screen.
3. Play from:
--Compact flash card (CF card)
--USB flash drive
--Built-in memory (Optional)
--Compact flash card (CF card)
--USB flash drive
--Built-in memory (Optional)
4. Update contents of the memory card (or built-in memory) by simply inserting an USB flash drive, no need to take out of the memory card.
5. Timer function: the player powers on / off automatically everyday at the pre-set time
6. Audio output: 2 X built-in high quality stereo speakers.
7. IR (infrared) body sensor: player starts automatically when the sensor detects an approaching viewer; this function can be disabled or enabled.
8. By pressing a combination of function keys on the player, the function keys themselves can be disabled or enabled.
9. Theft-protection device effectively prevents the player and CF (or SD) card from being stolen in public place.
10. With professional easy-to-use stand set; Easy-to-install on supermarket shelf, desk top, showcase, car and taxi, etc.
| Model | AD913WPT | |
| LCD Screen | LCD Size: | 9 Inch |
| Active Area: | 198.0 (W) * 112.08 (H) (mm) | |
| Pixel Pitch: | 0.2475 (W) * 0.2335 (H) (mm) | |
| Screen Ratio: | 16:9 | |
| Resolution: | 800 x 480 (H*V) | |
| Brightness: | 200cd/m2 | |
| Color: | 262K/16.2M (6bit/6bit+FRC) | |
| Contrast Ratio: | 500:1 | |
| View Angle: | 70°/70°/50°/60°(L/R/U/D) | |
| Response Time: | 4.5/12.5ms | |
| Touch Panel | Type: | Capacitive Touch Panel |
| Surface Hardness: | =hardness of 2mm tempered glass | |
| Operation Pressure: | 10-100g | |
| Optical Clarity: | =95% | |
| Life Time: | >1,000,000 times | |
| Response Time: | <10ms | |
| Storage Tempeature: | -10°C~+60°C | |
| Operation Tempeature: | -20°C~+70°C | |
| Support Formats | Video: | MPEG1 (VCD), MPEG4 |
| Audio: | MP3, WMA | |
| Picture: | JPEG | |
| Play From | Memory Flash: | CF card, Max. 8GB. SD card is optional before production |
| Built-in Flash Memory: | Optional, confirm before production | |
| USB: | High speed USB 2.0 (Host) | |
| Installation | VESA: | Yes/Optional 50 * 50 mm & 75 * 75 mm |
| Desk Stand: | Yes/Optional w/ Desktop Bracket | |
| Self Bracket: | Yes/Optional w/ Self Bracket | |
| Wall Mounting Bracket: | Yes/Optional w/ Wall Mounting Multi-angle Bracket | |
| Others | IR body Sensor Distance: | 3m |
| Remote Controller Distance: | 4-5m | |
| Input Voltage: | AC100V-240V (50HZ-60HZ) | |
| Power Supply: | DC1A, 12W (MAX) | |
| Speaker: | Built-in 2x2W high quality stereo loudspeakers | |
| Working Temperature: | 0°C-45°C | |
| Storage Temperature: | -20°C- 60°C | |
| Working Humidity: | 20%-80% | |
| Storage Humidity: | 10%-95% | |
| Casing: | Plastic (ABS + PC) | |
| Body Size: | 330(L) * 190(W) * 40(H) (mm) | |
| Body Weight: | 1.1 (kg) | |
| Package | Standard Accessories: | AC power adaptor, L shape bracket, User's manual or CD, Remote control, Power port cover |
| Unit Size: | 40 * 24.5 * 13.5 (cm) | |
| Unit Weight: | 1.9 (kg) | |
| Carton Size: | 70 * 41.5 * 27 (cm) | |
| Carton Weight: | 10.5 (kg) | |
| Units Per Carton: | 5 pcs | |
