7 Inch Lcd Point of Sale Touchscreen In-store Display

Specifications

1. 7" brand new multi-touch screen
2. long timer play and auto replay
3. ir motion sensor, timer function
4. CE, FCC, ROHS

7 inch lcd point of sale touchscreen in-store display

7 inch touch screen advertising player, suitable for supermarket, chain store, retail shop, media company, convenience store, airport, bus station, etc.



7 inch ads player in some occasions





Main Function




1. Play video by simply touching a screen icon corresponding to the video. Easy-to-install on supermarket shelves, desk top,showcase, car and taxi, etc.



2. Play from: -Compact Flash card (SD card) -USB flash drive -Built-in memory.




3. Upgrade contents of the memory card (or built-in memory) by simply inserting an USB flash drive, no need to take out of the memory card.



4. Timer function: the player powers on / off automatically everyday at the time pre-set.







5. Highly interactive, multi-layer touching screen.







6. The player will stop playing and go back to the upper level of menu once any area is touched by a viewer during playing.







7. No DVD style mechanical movement, hence more durable and suitable for long-hour advertising playing.







8. IR (infrared) body sensor: player starts automatically when the sensor detects an approaching viewer.







9. Theft-protection device effectively prevent the player and SD card from being stolen in public place.







10. Audio output: 2 X built-in high quality stereo speakers.







11. With professional easy-to-use stand set; can be installed on desktop, self edge, showcase, wall, car and taxi, etc.







LCD Screen	LCD Size:	7 Inch
	Active Area:	154.08 (W) * 85.92 (H) (mm)
	Pixel Pitch:	0.0642 (W) * 0.1790 (H) (mm)
	Screen Ratio:	16:9
	Resolution:	800 x 480 (H*V)
	Brightness:	250cd/m2
	Color:	262K/16.7M
	Contrast Ratio:	500:1
	View Angle:	70°/70°/50°/70°(L/R/U/D)
	Response Time:	10/15ms
Touch Panel	Type:	4 Wire Resistive Touch Screen
	Surface Hardness:	≥3H
	Operation Pressure:	10-100g
	Optical Clarity:	≥76%
	Life Time:	>1,000,000 times
	Response Time:	<10ms
	Storage Tempeature:	-10°C~+60°C
	Operation Tempeature:	-20°C~+70°C
Support Formats	Video:	MPEG1 (VCD), MPEG4
	Video Resolution:	720*480P
	Picture:	JPEG
Play From	Memory Flash:	SD card, Max. 8GB.
	Built-in Flash Memory:	Optional, confirm before production
	USB:	High speed USB 2.0 (Host)
Installation	VESA:	Yes/Optional w/ various kinds of VEVA convertors/Hang eyelets
	Desk Stand:	Yes/Optional w/ Desktop Bracket
	Self Bracket:	Yes/Optional w/ Self Bracket
	Wall Mounting Bracket:	Yes/Optional w/ Wall Mounting Multi-angle Bracket
Others	IR body Sensor Distance:	3m
	Remote Controller Distance:	4-5m
	Input Voltage:	AC100V-240V (50HZ-60HZ)
	Power Supply:	DC1A, 12W (MAX)
	Speaker:	Built-in 2x2W high quality stereo loudspeakers
	Working Temperature:	0°C-45°C
	Storage Temperature:	-20°C-45°C
	Working Humidity:	20%-80%
	Storage Humidity:	10%-95%
	Casing:	Plastic
	Body Size:	204(L) * 125(W) * 36(H) (mm)
	Body Weight:	0.6 (kg)



Your special needs, like printing logo, loading videos to memory card, buying extra accessories, are also available.
