Product Description of plastic washing recycling line
1.Masterbatch
2.Plastics modification
3.Fiber glass reinforcement
4.Cable compounds
5.Alloy plastics
6.Powder coating and toners, etc
Application:
1. Enhanced modification: PE, EVA, etc. with calcium sulfate, talc, titanium dioxide, carbon black;
2. Biodegradable Masterbatch: PE, PS etc. with starch, additives, etc.;
3. Flame retardant masterbatch: PE, EVA, etc. with antimony trioxide, magnesium hydroxide, aluminum hydroxide.
Reference Values
Mixing modification
PE,PP,PS+SBS,PA+EPDM,PP+NBR,NVA+silicon rubber,etc
PE,PA,PC,CPE+ABS(ALLOY),ABS+TPU,PBT+PET,PE+PP,etc
Filling modification
/ PE,PP,EVA,etc+Calcium carbonate,talcum power,titanic powder
/ABS,PC,PS,etc+aluminum hydroxide,magnesium hydroxide, antimony oxide
/ PP,PA,ABS+ferrous powder,sulphuric powder,ceramic powder
Functional masterbatch
PBT,etc+burning agent and other auxiliary agents: combustion-supporting machine pellets
PP,PE,PS etc+starch:de-composing machine pellets
PE+fog-preventing dipper,stabilizer: dual-prevention machine pellets
PE,EVA,ABS+carbon black:black machine pellets
Colored masterbatch
PE,PP,ABS,AS,PA,EVA,PET+pigment and auxiliary
Carbon fibers reinforcemen
/PP,PBT,ABS,AS,PA,PC,POM,PPS,PET,etc+long fibers, small fibers,carbon fibers,crystals and so on
Various cables
/ HDPE,LDPF,LLDPE,MDPE,EVA,PVCetc+Insulating cables,coatings,PE peroxide,silicon alkyl crossing cables
Special materials
/ EVA heat-melting glue,polyurethane,fluorin rubber,fluorin plastics,PP cigarette filtering material and TPR sole material
Reaction extruding
/ Polyamide condensate,polyamide melting polymerization,polyamide polyethrne-adding,polycarbonate condensate,etc
Exhausting and Volatilization
/ Polystyrene oxide,high-absorbing resin,chlorine sulphur polyethylene Powder paint Polyester,ring oxide,lactide,polyurethane,acrylate
Co-rotating Parallel Twin-screw Extruder Features
1. Screw components designed by computer aids is kneading type, has excellent self-cleaning function,
the new kneading block design effectively avoid the problems of overheating and energy consumption.
2. According to process system and formula requirements, the unit can optimize its L/D ratio, barrel structure, screw array,
venting number and location, feeding method, electrical control methods etc. for rational allocation.
3. Granulation system: water-cooling strand pelletizing, air-cooling die face hot cutting, water ring die face hot cutting,
Eccentric water mist hot cutting, water and underwater die face hot cutting and so on.
4. Application: Filling Modification, glass fiber (carbon fiber) enhance various kinds of master batch,
rubber and plastics compounding, plastic alloys, functional master batch, Various kinds of electric cable material,
reactive extrusion. Devolatilization process, powder coating and so on..
TSE-65
Reference Values
Mode mm L/D R/MIN KW N.m KG/H
TSE-20 22 32-44 600 5.5 4 1-10
TSE-30A 31 32-48 600 15 119 5-40
TSE-40A 41 32-52 600 15 119 65-110
TSE-40B 41 32-52 400 22 263 90-150
TSE-52B 51.5 32-64 600 75 716 250-300
TSE-75B 71 32-64 600 132 1050 350-550
TSE-75D 71 32-64 600 220-250 1990 500-1000
TSE-95A 93 32-64 500 250 2387 600-1000
TSE-95B 93 32-64 600 315 2506 800-1200
TSE-135 133 32-64 500 750 7162 1500-2250
Security Protection:
upling can effectively protect the reduction gearbox from extrusion unit overload dangers.
2.water-cooling system and lubrication systems are all real-time online monitoring.
3.drive ead pressure and melt temperature are all equipped with alarm systems.
(Air-cooling hot face pelletizing system / Air-cooling die face pelletizing system)
Air-cooling die face pelletizing mainly used in materials whose moisture can easily result in product poor quality.
Since the material has no contact with water in the whole granulation process, so eliminating the dehydration part,
to avoid the second pollution of cooling water. The die face hot-cutting material particles look round, full and beautiful.
Auxiliary Equipment
(Electric control system)
(crusher )
(vibrating screen with cooling)
Our machine types:
1. Co-Rotating Parallel Twin Screw Pelletizing Extruders
2. Single Screw Pelletizing Extruders
3. Die Face Cut (Air Cooling) Pelletizing Extruders
4. Double Stage / Double Degassing Recycling Extruders
5. Crushers, Mixers, Storage Tanks, Vibrators, Granulators, Blowers
6. Extruder spare parts
