Usage:
BD-320A/420A/520A automatic stretch vacuum packaging is a thermoforming machine designed to pack food, such as meat, fish, vegetable, fruit, dry food, etc. The package is created directly by the machine using two rolls of film. The film is flexible. Vacuum with gas flushing is available as an option.
Model |
BD-320A |
BD-420A |
BD-520A |
Upper Film Width |
292mm |
392mm |
492mm |
Lower Film Width |
322mm |
422mm |
522mm |
Upper Film Thickness |
0.05-0.7mm |
0.05-0.7mm |
0.05-0.7mm |
Lower PE Film Thickness |
0.05-0.5mm |
0.05-0.5mm |
0.05-0.5mm |
Running Speed |
1-8cycles/min |
1-8cycles/min |
1-8cycles/min |
Max. Packing Size |
|
400x400x60mm |
495x500x60mm |
The Power of Heater |
|
13KW |
13KW |
Power Consumption |
|
15KW |
15KW |
Power Voltage |
380V/50HZ |
380V/50HZ |
380V/50HZ |
Approx. Machine Weight |
1300kg |
1700kg |
2100kg |
Approx. Machine Dimension |
5100x900x1800mm |
6150×1200×1900mm |
6200X1400x1900mm |
No. |
Item |
Brand |
1 |
PLC |
Mitsubishi, Japan |
2 |
Expansion Module |
|
3 |
Touch Screen |
Weinview, Taiwan |
4 |
Chain Drive Servomotor |
Mitsubishi, Japan (1KW) |
5 |
Vacuum Pump |
Bush, Germany |
6 |
Temperature Controller |
Shanghai Yatai, China |
7 |
Breaker |
Schneider, France |
8 |
Solenoid Valve |
Airtac, Taiwan |
9 |
Air Cylinder |
Airtac, Taiwan |
10 |
Solid State Relay |
Langning, China |
11 |
Mold Material |
Aluminum |
12 |
Machine Frame |
304 Stainless Steel |
1. All processing steps be done automatically , which saves labor and high efficiency .
2. This machine operation is convenient and stable performance .
3. One machine can make different products, just change the mould, It has multifunction .
4. Machine can be customized according to customer requirement .
