Automatic Clamshells Packages Thermoforming Machine With Forming-Vent Hole Punching-Cutting-Stacking Unit
- Ningbo
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Four Station Plastic Thermoforming Machine With Forming-Vent Hole Punching-Cutting-Stacking Unit
-
APT-540/760 Automatic Plastic Vacuum Pressure Thermoforming Machinery With Autostacker
-
Four Station Thermoforming Machine
-
Hydraulic Paper, Plastic Cup Lid Thermoforming Machine
-
PP Plastic Cup Lid Forming Machine
-
2014CE Standard DP-420F Tray Thermoforming Machine
Product Details
| Condition | New | Product Type | Other, Trays, boxes, blisters, plates, covers | |
| Place of Origin | Zhejiang, China | Brand Name | APT | |
| Voltage | 380V/50HZ | Warranty | 1 YEAR | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Automatic Thermoforming Machine With Forming-Cutting-Stacking
I. Main Features:
1- Positive forming and Negative Forming
2- PLC and Touch Screen
3- Fully automatic sheet feeding-forming-hole punching-cutting inline
II. Main Technical Parameter:
Max Forming Area | 760x540mm |
Max Depth of Draw under sheet | 120 mm |
Max Depth of Draw above sheet | 50mm |
Suitable material | PET, PP, PS, PVC |
Sheet Width | 500- 800 mm |
Material Thickness Range | 0.3-1.5mm |
Max. Sheet Roll Dia. | 1000 |
Cycles per Minute(dry run) | 20-25cycles/min |
Power Supply | 3-N AC380V±15V |
Power Consumption | 90 KW/hr |
Air Pressure | 0.7Mpa |
Air Consumption | 2500 Liters/min |
Cooling Water Consumption | 13 Liters/min 15° - 20°C |
Approx. Machine Dimension | 9.5*2.2*2.4(L*W*H) |
III. Samples:
