Specifications
1.Fully compliant with DVB-T22.DVB subtitle supported
3.Multi-language OSD and user-friendly UI
Product: DVB-T2 HDTR821
solution:Mtar7802+MSB1236C+NMI120
picture:
1.Fully compliant with DVB-T2
2.USB2.0 for software update/PVR/media play back
3.Full HD output in 720p,1080i,1080p
4.HDCP protection
5.Time shift supported with external hard drive disc
6.DVB subtitle supported
7.Less than 0.5 Watt in standby
8.Multi-lingual OSD and user-friendly UI
9.Parental Control,Teletext,EPG supported
10.Support movie files with MPEG1/MPEG2/MPEG4/H264/VC-1/MOTION JPEG, so on.
11.Support music files with WMA/MP3/AAC(.wma/.mp3/.m4a)
12.Suport picture with JPEG, BMP, PNG
DVB-T2 ANT Input/Demodulation | |
| Connector Type | IEC-Female for ANT IN |
| Input Frequency | (UHF)470~866MHz,(VHF)170~230MHz |
| Bandwidth | 6,7,8MHz |
| Signal Input Level | -78 ~ -20dBm |
| Input Impedance | 75Ohm |
| ANT Power | 5V(On/Off),Imax=100mA |
| Demodulation scheme | QPSK, 16-QAM, 64-QAM, 256-QAM |
| Demodulation Type | OFDM, fully compliant with DVB-T2 Standard |
Media Features | |
| Picture | JPEG,BMP,PNG |
Power Supply | |
Adapter | |
| DC Input | 100-240VAC@50/60Hz |
| Power Consumption | 10Wmax |
Memory | |
| Flash | 32Mbit |
| DDRII Memory | 512Mbit |
Physical Characteristics | |
| Physical Size | 115mm * 75mm * 22mm |
Front Panel | |
| Remote Control input | Infra-red receiver |
| Indicator | LED Indicator for Power On/Off |
Rear Panel | |
| Connector | 1 * IEC connector for ANT IN |
| 1 * HDMI 1.3 Interface, up to 1080p | |
| 1 * RCA3(CVBS, L/R) | |
| 1 * USB2.0 | |
Remote Specifications | |
| Battery | (AAA 1.5V) * 2 |
| Operation distance | 8m Min.(front distance from receiver) |
| Operation angle range | ± 45 °(horizontal),± 20 °(vertical) |
Company Profile
HdmiSat Technology Co., Ltd is a fast growing company engaged in researching & developing, manufacturing and marketing a complete series of set-top box. We enjoy an excellent reputation from home and abroad with high quality products, competitive prices, personalized service and prompt delivery!
Company Scale
We are supported with a strong R & D team of more than 30 expericenced engineers and a strict QC team to inspect every process of production to ensure the best quality of our products. Moreover, we own a large-scale factory with an area of 8807.6 square meters and more than 400 workers for 10 production lines.
Product Strength
Our set-top boxes cover a diversified range of series: DBV-S/S2, DVB-T/T2 and ISDB-T. The product housing designs are dedicate and novel. Every component on the pcb is compliant with ISO Standard. Software update is timely and can be provided to our customers free of change for no time limitation. The functions of the STB are customized for every of our customers. Besides, by enhancing the production efficiency and making efforts in seeking and bargaining with our component suppliers to reduce cost in every aspect, our price is very competitive in the oversea market.
Oversea Market
Through the 15 years’ accumulation of experience and customer base, we develop step by step with our unremitting efforts and firm belief. Our oversea market is growing year by year including Africa, Middle East, South-East Asia, Russia and South America. We will never satisfy our achievement and stop advancing. The next strategy of us is to explore the markets of Western Europe, America and Australia and push our products to high-end products.
Mission and Commitment
we offer 1% spare after sales!
Master Box: 60*32.5*21.8cm 20pcs/carton GW:12.7KG or as per
Box: 1 pcs
Receiver:1 pcs
RCA cable: 1 pcs
Remote control:1 pcs
Battery:2 pcs
Power adapter:1 pcs
User manual:1 pcs
other:
You may like this:
You may need this:
satellite finder for T2:
