Model:HDTR881L (M3812 + CXD2837 + CXD2872)
Size:138*100*30mm (Plastics)
Standard:DVB-T2
Features:• Fully Compliant with DVB-T2 and DVB-T
• Support MEPG-4 AVC(H.264) MP/HPL4.1 Support MEPG-2 MPHL/ML
• HE AAC5.1, HE AAC+, DD, DD+ (Dolby is optional)
• Multi Bandwidth: 6M 7M & 8M
• Supports 64QAM, 16QAM and QPSK (4QAM) sub-carriers
• Video decoding and output: 1080p/1080i/720p
• Analog Video output: PAL/NTSC
• Conversion between SD programs and HD programs
• USB2.0 supported for upgrade, PVR and time shifting
• SupportParental Control,Teletext,Subtitle
• Aspect ratio: 4:3/16:9,By Pan & Scan and Letter Box conversion
• Electronic program guide (EPG)
• Software upgrade (OAD or USB)
• 32 bits true color OSD
• Program editor
• Support Favorite Group
• Support Audio Descripter function
| CPU and Memory | CPU | M3812 |
| MIPS 34K 600 MHz | ||
| DDR2 | DDR2 512Mbit(64MByte) | |
| Flash | 32Mbit(4MByte) | |
| DVB-T2 Standard | Fully compliant with ETSI EN 302 755 ( DVB-T2 ) | |
| Tuner | Connector Type | RF In/ANT In(IEC-Female) |
| Input Frequency | (UHF)470-866MHz, (VHF)170-230MHz | |
| Bandwidth | 6, 7, 8MHz | |
| Signal Input Level | -78-20dBm | |
| Input Impedance | 75 Ohm | |
| Active Antenna | 5V(On/Off), Imax=100mA | |
| Demodulation Scheme | QPSK, 16-QAM, 64-QAM, 256-QAM | |
| FFT | 1K, 2K, 4K, 8K, 16K, 32K | |
| FECE mode | 1/2, 2/3, 3/4, 3/5, 4/5, 5/6 | |
| Guard Interval | 1/4, 1/8, 1/16, 1/32, 1/128, 19/128, 19/256 | |
| Software Function | OS | ECOS |
| EPG | Fully support to 7 days Electronic Program Guide(EPG) | |
| Video Decoding | MPEG1, MPEG2, MPEG4, H264, VC-1, MOTION JPEG, MPG, MP4 | |
| Video Format | avi, mp4, mkv, mov, dat, flv, mpg, vob, 3gp, ts | |
| Audio Decoding | MPEG1-L1/L2/L3/, wma,AAC | |
| Audio Format | mp3, wma, ogg | |
| Picture Format | JPEG, BMP, PNG | |
| Video Resolution | 480i, 480P, 576i, 576P, 720P, 1080i, 1080P | |
| Video Aspect Ratio | 4:3(LB/SCAN), 16:9(LB/FIT) | |
| Analog Video System | PAL, NTSC | |
| OSD Language | 13 kinds of language(English,French,German,Italian,Spanish,Portuguese,Russia,Turkish,Polish,Arabic,Persian,Thai,Korean) | |
| LCN Sort | Support Logic Channel Number(LCN) | |
| Teletext | VBI insertion for Teletext,CC and WSS | |
| Time Shift | Support Time Shift | |
| Hardware Interface | Video Output | RCA(CVBS, L/R), HDMI Interface |
| SPDIF Output | none | |
| USB Interface | 1*USB2.0 | |
| Button | none | |
| Power supply | AC Input 100~240V 50Hz, 10WMax |
20pcs/carton, white box or gift box
Warranty : 12 months warranty
Company inside is managed as to the international convention that offering satisfactory products and services to customers. The motive power of Gecen development is pursuing customer satisfaction. We insist on customer-oriented philosophy which bringing long term business value to customers continually. Our flawless products and the large global market occupation that makes Gecen will be listed on the NEEQ and open a new chapter of evolution. Gecen will adhere to the corporate concept of being high capability, high efficient and forging ahead with determination and innovating constantly. Looking ahead the future, we are going to expand the business scale and be strong in product quality in the opportunities of TV communication industry development which brought by technology upgrade and consumption expand; we will deal with customers, staff, shareholders and the society on a win-win basis for the purpose of making Gecen be a top respectable and professional TV communication products manufacturer in the world.
What we are selling ?
LNB, Multiswitch, Diseqc switch, sat finder, splitter, HDMI splitter, T2 ,FTA S2. OTT
