6 pillars outdoor aluminum stage roof systems with sound wings
If you like this stage roof systems please tell us the width depth and height sizes, so that we can give you a detail quotation. thank you.
Aluminum stage roof systems detail
| Dimention | 12x10meter /40x30ft or your sizes |
| Sound wings | 2m/ 6.56ft |
| Height | 5-9 meter 16-30ft |
| Beam truss | heavy duty 400x400 truss /15.7x15.7in |
| pillar truss | 300x300mm/ 11.8x11.8in |
| UDL loading | 4000kg |
| Sound wing loading | 2000kg each side |
| Roof cover | PVC fabric waterproof 650g/m2 |
| volume | about 27m3 |
| Weight | about 4000kg |
size |
Main tube |
Horizontal tube |
Brace tube |
Material |
connection |
200*200mm |
30*2mm |
12*2mm |
12*2mm |
6061T6 |
Screw/bolt |
220*220mm |
30*2mm |
12*2mm |
12*2mm |
6061T6 |
Screw/bolt |
250*250mm |
50*3mm |
20*20mm |
20*2mm |
6061T6/6082T6 |
Screw/spigot |
300*300mm |
50*3mm |
25*2mm |
20*2mm |
6061T6/6082T6 |
Screw/spigot |
350*350mm |
50*3mm |
25*20mm |
20*2mm |
6061T6/6082T6 |
Screw/spigot |
300*400mm |
50*3mm |
30*2mm |
25*2mm |
6061T6/6082T6 |
Screw/spigot |
400*400mm |
50*3mm |
30*2mm |
25*2mm |
6061T6/6082T6 |
Screw/spigot |
450*450mm |
50*3mm |
50*2mm |
25*2mm |
6061T6/6082T6 |
Screw/spigot |
500*500mm |
50*3mm |
50*2mm |
25*2mm |
6061T6/6082T6 |
Screw/spigot |
500*600mm |
50*3mm |
50*2mm |
30*2mm |
6061T6/6082T6 |
Screw/spigot |
520*760mm |
50*3mm |
50*2mm |
30*2mm |
6061T6/6082T6 |
Screw/spigot |
600*760mm |
50*3mm |
50*2mm |
30*2mm |
6061T6/6082T6 |
Screw/spigot |
Customer size |
|
|
|
|
|
stage roof systems gallary application
Peaked roof
Flat roof
Arch roof
Stage specification
1.Material: aluminum alloy 6061
2.Height : 0.6-0.8-1m or OEM*(adjustable)
3.Dimension: 1.22*2.44m/4'*8' (1.22x1.22m / 4'x4')or OEM
4.Plywood: thickness 18mm. Color : red , black , dull red , brown
antislip and waterproof
Packing and loading
