HX-210-A Paper Handkerchiefs Packing Machine

Specifications

This is the automatic packing machinery for pocket-handkerchief tissues
HX-210-A Paper Handkerchiefs Packing Machine

 HX-210-A Paper Handkerchiefs Packing Machine



Equipment Function & Character:



This is the automatic packing machinery of high quality for pocket-handkerchief tissues. Lts characters are fast speed, high efficiency and standard trim outlook, to avoid the abuses from hand-make. Lt applies the frequency conversion tinimg controlling system, Mitsubish’PLC touching and program controlling system. Inspect servo track automatically. At present, it is the most advanced equipment in the domain of china. It also achieved the international standard in the field, and completely replaces those imported equipments. It is the most ideal equiopment in the domain sanitary paper-manufacturing field.



Main Technical Parameter

1. Packages: L x W x H a. 75 x 52 x 26mm b. 105 x 52 x 26mm
2. Packing speed: 30~70 pkgs/min
3. Machine power: 4.68kw (380v 50Hz)
4. Air pressure: 0.3m3/min 0.3~0.4MPa
5. Overall size of equipment (L x W x H m): 3.6 6x 2.75 x 1.92
6. Weight of equipment: about 1.5t
