Co-extrusion Coating Station and Coater Laminator machine
Co-extrusion Coating Station and Coater Laminator machine
machine Main feature and performance
Model JDLF65x2-1000 adopts more advanced, more humanized PLC programmable controller. Mostly used for aluminum paper-plastic packaging material. such as alcohol packing..instant noodle box cover, toothpaste shell and so on.
Co-extrusion Coating Station and Coater Laminator machine
Main technical parameter
1.Screw and barrel:φ65mm with special mixed segment and high capacity. 2.Mold:T-flexible mold supporting auto filter change 3.Raw material laminating film: Laminating PE/PP, etc. 4.Laminating effective width:600-1000mm 5.Laminating film thickness:0.012-0.035mm,single. 6.Mechanical design speed:0-150m/min 7.Unwinding:High-speed non-stop automatic cutting 8.Winding:High-speed non-stop automatic cutting.
Co-extrusion Coating Station and Coater Laminator machine
PART1: Unwnding system
Unwinding substrate requirements |
80~350gsm Roll paper 0.006~0.007mm Roll of aluminum foil |
Mechanical design speed |
0~150m/min |
Unwinding |
High-speed non-stop automatic cutting |
Co-extrusion Coating Station and Coater Laminator machine
PART2: Extruding system
Screw and barrel |
Φ65mm with special mixed segment and high capacity |
Mold |
T-flexible mould supporting auto filter change |
Raw material laminating film |
Laminating film machine PE,PP, resin, etc. |
Effective film width |
600~1000mm |
Laminating film thickness |
0.012~0.03mm Single |
Laminating evenness |
±5% |
Co-extrusion Coating Station and Coater Laminator machine
Part3: molding system
Co-extrusion Coating Station and Coater Laminator machine
Winding type |
central type |
Max diameter |
1200mm |
tension |
Controlled by inverter motor |
Roller change |
Manual |
Winding |
High-speed non-stop automatic cutting |
Co-extrusion Coating Station and Coater Laminator machine
Part 5: sample pictures
Co-extrusion Coating Station and Coater Laminator machine
Why chose us
1. At the same quality grade, our products' price is better.
2. At the same products' price level, our service is better
3. 5-9 days delivery,guaranteed
Co-extrusion Coating Station and Coater Laminator machine
PART 6:factory pictures
Co-extrusion Coating Station and Coater Laminator machine
PART 7:with customers
Co-extrusion Coating Station and Coater Laminator machine
PART8:certificates
Jiangyin City Yuzhe International Trading CO.,LTD
Jiangyin City Yuzhe International Trading CO., LTD., has 30 years of industrial experience. We are the leader of in the production of soft plastic package such as coating machine ,blowing and printing machine and act. we have independent import and export corporation and the factory entitled research , design and production .
Co-extrusion Coating Station and Coater Laminator machine Best service! Best quality! Best price!
...
