YAG metal laser cutting machine
Product Feature
1.Adopt YAG solid laser optics system, good optical patch, smaller gap, high precision.
2.Imported automatism following cutter head with capacitance model,
moving without touch material directly, keep laser focus stable distance.
3.Adopt double linear guide positional method, ball screw transmission, high speed, high precision, stable moving performance.
4.Could be auto-importing drawing to process, manual setting program is unnecessary.
Technical Parameter
| Specification | |||||
| Model | DW-YAG 1530 | ||||
| working area | 1500*3000mm | ||||
| Laser Type | YAG lamp-pumped solid laser generator | ||||
| Laser power | 500W | ||||
| Laser wave length | 1064nm | ||||
| cutting speed | ≤2100mm/min | ||||
| Cutting thickness | 0.2-6mm (according to material) | ||||
| resetting precision | ±0.02mm | ||||
| minimum line width | 0.15mm | ||||
| impulse frequency | 1-450Hz | ||||
| Transmission Method | Servo motor, Ballscrew | ||||
| Cooling method | 7P Water cooling | ||||
| Gross power(W) | <20KW | ||||
| Power supply | 380V/50HZ or 60HZ/60A | ||||
| Supporting Format | PLT, DXF, BMP, AI, DST, DWG, etc. | ||||
| net weight(kg) | 2500kg | ||||
Why Fiber laser cutting machine better than YAG or CO2 laser cutting machine
Fiber laser cutting machine has a far exceed than YAG or CO2 laser machine. As the fiber laser can be more absorbed by the cutting metal, and the fiber laser power is pretty stable. Also the fiber laser machine consume less because of less mirrors and no consumables. Even the cooling water chiller is 1P compared with the YAG machine use 7P water cooling.
Packing & Shipping
1.Durable plyooden case or as per required.
2.The delivery lead time would be 12-15 working days after receiving the payment.
3.As for the wholesalers/distributors,we could send the cargo by air,by sea or by railways via reliable forwarder.
Application
Widely used in sheet-metal structure,high-low-voltage electrical cabinet production,hardeware,knife-volume,production of advertising signs,metal crafts,decoration aviation,, mechanical meter,saw blades,spring-chip and other industries.
It's applied to cut stainless steel,carbon steel,alloy steel,spring steel,aluminum,sliver,copper,titanium and some metal plate and pipe.
Service
| 24/7 service is available to each customer. And if any technical questions or problems, our engineers will help you and give you solutions on the phone or by face-to-face communication online. |
| One-year warranty is provided. (The detailed reference will be written into the final contract.) |
| Professional staff for installation and training if needed. |
| Spare parts are supplying on time or doing some inventory if promising certain sales volume. |
| Faster delivery, we will support our sole agent to do the stock if good sales, then more convenient and helpful. |
If the sales are good, we will arrange some famous exhibition fairs in the local or surroundings, and give our full support to our agents at the fair. We will provide our sample machines, catalog, DVD, manuals, etc. All native customers belong to our local agent, which is our basic rule. And we promise the final delivery is the same as displayed prototype. |
Samples
About Us
Our metal cutting machine is heavy body with 8mm thick square tube welding,Patent product ,the only manufacture adopt square tube framework in China,with higher strength than ordinary ones.Please ensure the machine you purchased is the one with tube framework.
High quality is our forever pursuit,we adopt original imported components,advanced manfacturing technology,large mass production and high standard testing,perfect after sale service,won customers' trust and support."Customer first,credit first" is our highest faith,through our persistent effort,we believe,we will build a brilliant future with you.
