3-way electric forklift

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

especially suitable yo use in very narrow aisles. Aosle width 1.47m-1.71m according to your pallet size.

Model	TC10-60
Kg Loading Capacity	1000
mm Lifting height	6000
mm Load center	500
mm Overall length	3764
mm Outer width of forks	260-756
mm Mast height(closed)	3250(triplex free lift mast)
mm Overall width	1450
mm Min.width aisle	1480(1000*1000mm pallet)
mm Side shifter distance	1060/1160
Fork rotation time	12
mm/s Fork side shift speed	240
Km/hDriving speed Unload/Load	8.0/7.0
mm/s Lifting speed Unload/load	315/180
mm Fork size	107010035
mm Driving wheel	Φ380×165
mm Front wheel	Φ140×100
mm Balance wheel	Φ204×76
Total weight(with battery)	5300
Kw Lifting motor	7.5
Kw Driving motor	5.5(AC)
V/AH Battery	48/400
V/A Charger	48/50
