CO2 laser cutting machine 1325 150w CO2 laser cutting 1325laser cutting machine CO21325 laser cutting machine
CO2 1325 laser cutting machine metal and non-meta laser cutting
High quality GSI 1325 150w CO2laser cutting machine for metal and Non-metal cheap
Application: Laser cutting Condition:new Laser Type:co2 Transmission system:Ball screw and Linear tube
Driving system:3Axial servo Chiller system: Special Chiller system for imported laser tube
Product feature
1 optional imported 200w/300w GSI laser tube has perfect beam of light quality and high efficiency photovoltanic conversion,the life-span can up to 15000hours
2 Open can use ,no start machine fare,low consumption
3 High quality ball screw&linear guide transmission system
4 Imported Japanese Mitsubishi/Panasonic servo system
5 Auto-focusing system and automatic tracking system can keep the precision processing
6 Reasonable structure design can ensure good rigidity and efficient smoke removing system
7Thicking steel plate design and scientific assembly process control insure machine high precision and performance
Technical Parameter
Laser output power |
Domestic 150w,optional 200w/300w |
| X-axis travel-length | 1250mm |
| Y-axis travel-length | 2500mm |
| Positioning Precision | 0.05mm/m |
| Max. speed of moving | 10m/min |
| Controling sysstem | Movement control card/NC |
| Transmission system | Ball screw&Linear guide |
| Driving system | 3 Axial servo |
| Optical system | Semi-optical |
Moving structure |
Gantry |
| Chiller system | Special Chiller system for imported laser tube |
| Overall dimension | 4200*2100*1400mm |
| Weight | 2000kg |
| Structure | open |
| Power supply | 380V/50HZ/30A |
Applicable material
stainless steel ,carbon steel,galvanized plate,cutter templates,wood sheet,acrylic,organic glass,MDF,leather,composite maerial
Key parts
Technical Support:by calling or email or training
24 hours technical support by emails, fax or calling.
Free training in our factory. Also we can dispatch our technician to customers'
place if customer agrees to air ticket, food and hotel.
packing details:standard plywood case
shipping detailes:10 days
Jinan Dowell Photoelectricity Equipment Co,Ltd ,with12 years production experience ,specialized in laser cutting ,engraving,marking equipment production ,developing and sales,and provide customers with comprehensive solutions,compared to same industry ,we are one of hold the autonomy Research and Development companies in this fied ,all series of product have passed CE,FDA,and others international certification
High quality is our forever pursuit,we adopt original imported components,advanced manufacturing technology ,large mass production and high standard testing,perfect after sale service,won customers' trust and support,
'' Customer first ,credit first'' is our highest faith ,through our persistent effort,we believe,we will build a brilliant future with you
Q1:How long is the delivery time for 1325 laser cutter?
For standard machines, it would be 7-15 days;
For non-standard machines and customized machines according to client s specific
requirements, it would be 15 to 30 days.
Q2: What mode of payment for this 1325laser cutter?
T/T, 50% deposit and the balance 50% should be paid before shipment.
Q3: If some problems happened to this machine during warranty period,
what should i do?
We will supply free parts in machine warranty period if machine have some problem.
While we also supply free after-service forever,so any doubts,just let us know,we will
give you solutions in 30 minutes
Why choose Dowell?
1.Dowell product is widely used in almost all the materials which you can think of.
2.Dowell company is specialized in cnc router and laser machine manufacturing and selling. There is no middle man and no agent, so the price is best.
3.Dowell machine with high precision and high reputation is the most reliable goods you can choose.
4.Dowell company has all kinds machines in store, the delivery time is much shorter than other companies.
5.Dowell Company has international tech service office and provides 24 hours online service and tech support for customers.
Quality control
No best,only better. Dowell laser will create greater value for you
